CC2543 CC2592 Radio Remote Control UAV 2.4Ghz UART RF Module
US$ 3 - 4
/ Piece
2 Pieces(Min. Order)
- shenzhen
- T/T
- 7 days
You May Like
-
CC2543 CC2592 Radio Remote Control UAV 2.4Ghz UART RF Module
-
CC2543 CC2592 Radio Remote Control UAV 2.4Ghz UART RF Module
-
CC2543 CC2592 Radio Remote Control UAV 2.4Ghz UART RF Module
-
CC2543 CC2592 Radio Remote Control UAV 2.4Ghz UART RF Module
-
Cc2544 RF Dongle,2.4g,Wireless Audio Module,Wireless Audio Dongle
-
Cc2544 RF Dongle,2.4g,Wireless Audio Module,Wireless Audio Dongle
Product Details
| Brand Name | Coral RF | Place of Origin | China | |
| Model Number | N204 |
Product Description
Technical specifications
Hareware Information
Interfaces: UART (x1)
A/D & D/A converters
PWM timers
Dimension: 30 x 17 x 3 mm
Operating voltage:3.3V
Operating temperature: -40°C to +85°C
Consumption (Sleep): 1uA
Consumption (RX): 17mA
Consumption (TX): 170mA (20dBm)
Wireless Micro-controller: CC2543
Mounting: SMD
Software
Asynchronous Transparent mode
Low Power mode
Secure mode
RSSI mode
Serial bootloader
Adjustable packet size
Wireless Interface
RF pin,IPEX
Frequency: 2400 to 2483MHz
Modulation: 4GFSK, 2GFSK, 2FSK
RF data rate: from 250 to 2000 kbps
RF output power: up to 20dBm
RF sensitivity: -100dBm
