Home > Electrical & Electronics > Telecommunication & Broadcasting > WiFi Products > SX1272 LORA RF Module 1W 30dbm LORAWAN CE FCC
SX1272 LORA RF Module 1W 30dbm LORAWAN CE FCC
US$ 10 - 12
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
Coral RF
Place of Origin:
China
Model Number:
N417
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
7 days
Related Products
-
SX1262 SPI LORA RF Module,Wireless Module,RF Module,Long RangUS$ 5 - 10MOQ: 2 Pieces -
SX1262 LORA SPI RF Module,Wireless Module,RF Module,Long RangUS$ 5 - 10MOQ: 2 Pieces
-
SX1262 LORA SPI RF Module,Wireless Module,RF Module,Long RangUS$ 5 - 10MOQ: 2 Pieces
-
SX1262 LORA SPI RF Module,Wireless Module,RF Module,Long RangUS$ 5 - 10MOQ: 2 Pieces
-
SX1262 LORA SPI RF Module,Wireless Module,UART RF Module,Long RangUS$ 5 - 10MOQ: 2 Pieces
Brand Name
Coral RF
Place of Origin
China
Model Number
N417
Technical specifications
Hareware Information
Interfaces: IIC,UART,SPI
Dimension: 42 x 24mm x 3mm
Operating voltage VCC: 2 - 3.6V
Operating voltage VCCPA: 2 - 4.8V
Operating temperature: -30°C to +70°C
Consumption(Sleep) : 2uA
Consumption (RX): 25mA
Consumption(TX):1600mA(+33dBm )
RF chip: SX1272
Mounting: SMD
Software
Asynchronous Transparent
mode Low Power mode
Secure mode
RSSI mode
Serial bootloader
Adjustable packet size
Wireless Interface
RF pin,IPEX
Frequency: 868-960Mhz
Modulation: Lora
RF data rate: 1.2 - 37.5kbps
RF output power: up to 33dBm
RF sensitivity: -131dBm
