RB20030 Crossed Roller Bearing 200*280*30mm
US$ 10 - 500
MOQ: 5 Sets
Key Specifications
Get Latest Price
Brand Name:
RIGBRS
Place of Origin:
China
Model Number:
RB20030UU
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
45 days
Related Products
-
RB20035 Crossed Roller Bearing 200*295*35mmUS$ 10 - 500MOQ: 5 Sets -
RB19025 Crossed Roller Bearing 190*240*25mmUS$ 10 - 500MOQ: 5 Sets
-
RB12025 Crossed Roller Bearings 120*180*25mmUS$ 10 - 500MOQ: 5 Sets
-
RB13015 Crossed Roller Bearings 130*160*15mmUS$ 10 - 500MOQ: 5 Sets
-
RB13025 Crossed Roller Bearings 130*190*25mmUS$ 10 - 500MOQ: 5 Sets
Brand Name
RIGBRS
Place of Origin
China
Model Number
RB20030UU
Feature
Cross Roller
Seals Type
sealed both sides
Outside Diameter
36, 220
Bore Size
20, 160
Gear Options
Nongeared
RB20030UU crossed roller bearings spacifications
size: 200*280*30mm
structrue: single row crossed cylindrical roller bearings with separable outer ring and integrated inner ring.
sealing: sealed both sides
clearance: CC0/C0
precision: P5/P4
RB20030 cross roller ring has thin section(slim type), so it's suited for where space is limited, and inner ring running accuracy is required.
RB series crossed roller bearing provides high and stable running accuracy, suited for precision detecting instrument, robot joints, direct drive torque motor, high-precision turntable, etc.
| Model No. | d (mm) | D (mm) | B (mm) | C (KN) | Co (KN) | kg |
| RB17020 | 170 | 220 | 20 | 29 | 62.1 | 2.21 |
| RB18025 | 180 | 240 | 25 | 84 | 143 | 3.44 |
| RB19025 | 190 | 240 | 25 | 41.7 | 82.9 | 2.99 |
| RB20025 | 200 | 260 | 25 | 84.2 | 157 | 4 |
| RB20030 | 200 | 280 | 30 | 114 | 200 | 6.7 |
| RB20035 | 200 | 295 | 35 | 151 | 252 | 9.6 |
| RB22025 | 220 | 280 | 25 | 92.3 | 171 | 4.1 |
| RB24025 | 240 | 300 | 25 | 68.3 | 145 | 4.5 |
| RB25025 | 250 | 310 | 25 | 69.3 | 150 | 5 |
| RB25030 | 250 | 330 | 30 | 126 | 244 | 8.1 |
| RB25040 | 250 | 355 | 40 | 195 | 348 | 14.8 |
| RB30025 | 300 | 360 | 25 | 76.3 | 178 | 5.9 |
| RB30035 | 300 | 395 | 35 | 183 | 367 | 13.4 |
| RB30040 | 300 | 405 | 40 | 212 | 409 | 17.2 |
| RB35020 | 350 | 400 | 20 | 54.1 | 143 | 3.9 |
| RB40035 | 400 | 480 | 35 | 156 | 370 | 14.5 |
| RB40040 | 400 | 510 | 40 | 241 | 531 | 23.5 |
| RB45025 | 450 | 500 | 25 | 61.7 | 182 | 6.6 |
| RB50025 | 500 | 550 | 25 | 65.5 | 201 | 7.3 |
| RB50040 | 500 | 600 | 40 | 239 | 607 | 26 |
| RB50050 | 500 | 625 | 50 | 267 | 653 | 41.7 |
| RB60040 | 600 | 700 | 40 | 264 | 721 | 29 |
| RB70045 | 700 | 815 | 45 | 281 | 836 | 46 |
| RB80070 | 800 | 950 | 70 | 468 | 1330 | 105 |
| RB90070 | 900 | 1050 | 70 | 494 | 1490 | 120 |
| RB1000110 | 1000 | 1250 | 110 | 1220 | 3220 | 360 |
| RB1250110 | 1250 | 1500 | 110 | 1350 | 3970 | 440 |
