Exhalation Gas Alcohol Detector Testing DeviceUS$ 500000 - 700000MOQ: 1 Unit
1. System name: device for testing the breathable gas alcohol content detector
Ii. System model: CBD-JJG657
Manufacturer: nico instruments
Iv. System introduction
Exhaled gas alcohol content detector is the main law enforcement tool used by public security traffic departments to quickly detect the breath alcohol content of vehicle drivers on the spot.My company according to the law of the People's Republic of China national metrological verification regulations JJG657-2019 ", using the GB/T 5275 gas analysis dynamic calibration prepared with mixed gas volume "of dynamic distribution method using liquid ethanol and acetone ethanol and acetone gas standard gases preparation, and according to the content of alcohol breath gas detector structure and use of the characteristics of the developed breath gas alcohol detector CBD - JJG657 metrological verification standard device, the device is suitable for GB/T 21254-2017, OIML R - 126 (2012) standard.
CBD - JJG657 breath gas alcohol tester calibration device mainly consists of zero order standard gas generator air generator, ethanol, acetone gas generator, temperature, pressure flow control system, the differential measurement system, high precision of ethanol gas analyzer, touch LCD control system, carbon monoxide standard gas, ethanol gas standard gas (primary standard substance).
The schematic diagram of the detection device system of breathable gas alcohol content detector is as follows (2 channels can work simultaneously) :
V. overview of system functions
1. Error verification of indication value:
Select the "indicator error" option, and select the concentration value of ethanol gas to be verified (0.10 mg/L, 0.40 mg/L, 0.60 mg/L). The system will automatically output the standard gas with the specified concentration of 15 L/min, and the output time of the standard gas can be set.After the end of the timing can output zero gas and can set the output time of zero gas.
2. Repeatability test:
Select the "repeatability" option, and the system will automatically output the ethanol standard gas with the concentration of 0.40 mg/L and the flow rate of 15 L/min, and the output time of the standard gas can be set.After the end of the timing can output zero gas and can set the output time of zero gas.
3. Zero drift test:
Select the option of "zero drift", the system will automatically output zero-level air with zero concentration and 15 L/min flow, and the output time of zero-level air can be set.
4. Indicator drift test:
Select the option of "indicator drift", the system will automatically output the ethanol standard gas with the concentration of 0.40mg /L and the flow rate of 15l /min, and the output time of the standard gas can be set.
5. Anti-interference ability test:
Select the option of "anti-interference ability (acetone)", the system will automatically output standard acetone gas with concentration of 0.5 mg/L and flow rate of 15 L/min, and the output time of standard gas can be set.After the end of the timing can output zero gas and can set the output time of zero gas.
Select the option of "anti-interference ability (carbon monoxide)", the system will automatically output carbon monoxide standard gas with a concentration of 0.2 mg/L and a flow rate of 15 L/min, and the output time of the standard gas can be set.After the end of the timing can output zero gas and can set the output time of zero gas.
6. Memory retention effect test:
Select the option of "memory residual effect", select the concentration of the output ethanol standard gas (0.1 mg/L or 0.4 mg/L), the automatic flow rate of the system is 15 L/min of the ethanol standard gas, and the output time of the standard gas can be set.
7. Expiratory resistance test:
Select the "expiratory resistance" option, the system automatically outputs the zero point gas with the specified constant flow rate, and the output gas time can be set;After the end of the timing time, the system automatically slowly increases the gas input flow until the flow reaches 12 L/min, and the gas is output at a constant flow rate.Connect the measuring system as shown below:
8. Minimum expiratory flow and minimum duration test:
Select the option of "minimum expiratory flow rate and minimum duration", select the zero gas with the flow rate of the output zero gas (
Select the zero gas with a flow rate of 36 L/min for the output zero gas, and set the time for the output gas. The system will automatically output the zero gas with a flow rate of 36 L/min, and the flow rate will automatically drop to 6 L/min when the output gas reaches 2.0 seconds.
9. Measurement range verification:
Select the "measurement range" option, the system will automatically output the ethanol standard gas with concentration of 2.0 mg/L and flow rate of 15 L/min, and the output time of the standard gas can be set.
Description of system functions: system functions can be customized according to customers' usage habits and specific needs.
Verification item list and realization method:
Serial number verification item operation mode
Visual and manual inspection of appearance and structure
2 marks and marks visual and manual inspection
Power check visual and manual
Keep and store results visually and manually
Resolution and unit of measurement conversion visual and manual
6. Automatic measurement range
Minimum expiratory flow and minimum duration automatically
Display error automatically
9 repeatability
10 drift auto
11. Automatic anti-interference capability
12. Memory retention effect is automatic
Automatic expiratory resistance
Vi. Schematic diagram of system principle
1. Schematic diagram of verification device of breathable gas alcohol content detector (single channel)
2. Zero-stage air generator:
The zero-stage air generator is composed of the zero-stage air generator and the external air compressor system.The zero gas generator includes: pressure regulating device, gas cleaner, reaction chamber and temperature controller.The compressor system will compress the air and input it into the zero gas generator. The zero gas generator will produce zero level air without the pollution gas (such as SO2, CO, O3, NO, NO2 and HC).The schematic diagram of zero-level air is as follows:
Technical parameters
1. Ethanol gas generator output concentration range: 0 ~ 2.0 mg/L
2. The mass concentration uncertainty of ethanol gas generator is: ≤3.0%, k=2(@0.1mg /L);≤2.0%, k=2(@0.4mg /L);2.0% or less, k = 2 (@ 0.4 mg/L)
3. Output concentration of acetone gas generator: 5.0mg /L
4. Mass concentration uncertainty of acetone gas generator: ≤4.0%, k=2(@0.5mg /L)
5. The ethanol and acetone gas generator can work continuously for > for 24 hours for a long time
6. The system can be extended to two output verification ports, supporting the simultaneous verification of two wine detectors
7. The gas output flow rate of the verification port is 0 ~ 36 L/min, continuously adjustable
8. Fluctuation of gas output flow rate at the verification port:
9. Accuracy of gas output flow at the verification port: ± 0.3% RD
10. Gas output temperature of the test port: 34 ℃ ± 0.5 ℃
11. The precision of ethanol analyzer: 1.5% or less (@ 0.1 mg/L), 0.5% or less (@ 0.4 mg/L), 0.5% or less (@ 0.16 mg/L)
12. Atmospheric pressure measurement: resolution 1 hPa, MPE ± 2.5 hPa
13. Temperature scale: range 0 ~ 34 ℃, MPE ± 0.2 ℃
14. Operating voltage of the system: AC220 50Hz
15. Operating temperature of the system: 5 ~ 40 ℃
Viii. System configuration list
1. Test device of breathable gas alcohol content detector
2. Zero gas generator
Carbon monoxide cylinder gas
4. Ethanol cylinder gas (grade I standard material)
5. Ethanol standard gas generator or ethanol cylinder gas (optional)
6. Acetone standard gas generator or acetone cylinder gas (optional)
7. A stopwatch
8. Pressure reducing valve
9. Blown tee connector for wine detector
10. Ptfe tubes
