TD04HL 43.75/57.25mm 6+6 Blades Turbocharger Milling/aluminum 2618/billet Compressor Wheel
US$ 45 - 45
/ Piece
1 Piece(Min. Order)
- T/T Credit Card
You May Like
-
TD05H 20G Upgrade Forward 56.58/73.04mm 5+5 Blades Turbocharger Milling/aluminum 2618/billet Compressor Wheel
-
K04 5+5 Blades 49.62/68.58mm High Performance Turbo Milling/aluminum 2618/billet Compressor Wheel
-
TD03 39.10/46.00mm 11+0 Blades High Performance Turbocharger Milling/aluminum 2618/billet Compressor Wheel
-
TD03 31.00/39.98mm 6+6 Blades High Performance Milling/aluminum 2618/billet Compressor Wheel for 49173-02010
-
B03G Reverse 7+7 Blades 59.00/76.00mm High Performance Turbo Billet/milling/aluminum 2618 Compressor Wheel
-
GT2871 452546-0005 53.11/70.98mm 6+6 Blades Turbo Milling/aluminum 2618/billet Compressor Wheel for 452546-0005/Trim56
Product Details
| Brand Name | NO | Model Number | TD04HL | |
| Warranty | 12 Months |
Product Description
1. MODEL:TD04HL forward
2.TD04HL 43.75/57.25mm 6+6 blades Turbocharger Billet/milling/aluminum 2618 compressor wheel
3.Size:
Nose diameter:11.00mm
Inducer:43.75mm
exducer:57.25mm
Tapered tip exducer:58.44mm
Tip height:5.25mm
Superback:1.90mm
bore size :5.00mm
Overall height:26.67mm
Trailing angle:38
Cutback:5.0
SP height angle:-1.00
Blade height:22.00mm
Splitter height:14.70mm
6+6 blades forward
Tapered tip angle:18 degree
It is custom size ,please check carefully before buying.
4.High quality and competitive price.
5.if you want more details, please send email to me.
All the compressor wheel have been balanced.
