Diesel Fuel Injection Pump Test Bench and Common Rail Injector Test Bench China Pump Testing Machine

CR819  Common Rail Pump And Injector Test Bench (With HEUI (C7 ,C9,C-9 3126 )FUCTION ,WITH HEUI PUMP FUCTION )

  Function

1. High-precision flow measurement, it use imported flow sensor, high precision, good repeatability.

2. Test a comprehensive, test injector full load, medium speed, idle, pre-spray and other conditions of the fuel injection.

3. It can test BOSH, DENSO, DELPHI, SIEMENS, CAT etc injector

4. Machine low noise, it is using frequency control, speed prefabricated, low noise, no impact.

5. Advanced control, a key selection, the whole process of detection.

6. Massive data,

7.Open data management, the user can add the injector data itself, especially for the new fuel injector standard oil calibration.

8.It with pump flow sensor, it works with high pressure rail sensor to test common rail pumps.

9.It can test CP1, CP2,CP3 ,HP0 etc high pressure common rail pumps.

10. It with Cambox can test EUI EUP and HEUI

  Technical parameter

1. Out put power: 11kw

2. Input power: 380V/50hz/3phase or 220V/60hz/3phase

3. Rotation speed: 0~3000RPM

4. Rail high pressure: 0~2000 bar

5. Test oil filtered precision: 5μ

6. Oil tank: 60L

7. Size: 1900*900*1500

8. Wight: 800kg

Main products include:
     1, Diesel engine parts (nozzle, plunger, delivery valve, head Rotor, injector, fuel pump and other accessories) 2,  Injection pump test bench 3,auto tools 4  Auto parts 5, special vehicles 6 , Turbocharger.......
     Production process using advanced computer control and digital display systems, production technology, strong technical force . High quality, high technical performance, with micro-controller and digital functions. Products are sold  more than 100 countries and regions of all world .
