CRS200 Common Rail System Tester,common Rail Diesel Injector Test Bench

CRS200 common rail system tester,common rail diesel injector test bench

This Tester is designed to test a high-pressure common rail system dedicated machines, using high-speed 32-bit ARM7 core microcontroller as the master, is responsible for collecting the signal and control, compatible with MCS-51 microcontroller and dot matrix 5.7 inch LCD screen realization of man machine exchange, to complete the high-pressure common rail system functional test.

1, TESTER using the range:

This system is suitable for detection of Bosch, Denso, Delphi common rail system uses a variety of pumps. Rail and injectors

Such as: cp1 cp2 cp3 hp3 series type oil pump and the injector. Use this device installed in the pump test stand .The required testing and injection Common Rail Common Rail fuel pumps installed in the specified location, connected to the operation of the device power test rig can be detected under the related instructions.

2,Main technical parameters
(1) Jet injector device turn-on voltage
Control range: 24V, 80V, 150V
Control accuracy: phase adjustment
(2) Injector open frequency
Control :0-1000Hz
Control accuracy: 1Hz
(3) Fuel Injector Hold Time
Control :0-65535us
Control accuracy: 1us
(4) Quantity of oil times
Control 0-1000
Control accuracy: 1
(5) Pump models: CP1, CP2, CP3, HP0
(6) Hydraulic control
Control :0-200Mpa
Control accuracy: 1Mpa
Control: PID
(7) Power: ~ 220V
(8) Instrument working temperature: 0 ~ 40 ℃
(9) Relative Humidity: 20 ~ 90% RH

 Packing details: Wooden case

 Delivery details: 3-7 days after payent
