12PSB Fuel Injection Pump Test Bench,Spot Supply

12PSB fuel injection pump test bench.

Main technical parameter

1. Adjustable rotation speed range: 0~4000RPM;

2. Double series of graduates: 45/150CC;

3. Volume of oil tank: 100L;

4. Temperature stabilization: 40±2;

5. Test oil filtering unit: 5μ;

6. DC. Supply: 12/24V;

7. Feed pressure: 0~0.4MPa (low), 0~4MPa (high);

8. Air pressure (MPa): -0.03~0.3;

9. Rack travel range: 0~25mm;

10. 3-phase power supply: 380V/50Hz or on request.

Main function
1.Measurement of each cylinder delivery at any speed.
2. Test point and interval angle of oil supply of injection pump.
3. Checking and adjust the mechanical governor.
4. Checking and adjusting the distributor pump.
5. .Experiment and adjusting of behavior of supercharging and compensatory device.
6. Measurement of oil return of distributing pump
7. Testing of the electromagnetic valve of distributor pump.(12V/24V)
8. Measurement of the internal pressure of distributor pump.
9. Checking of the advance angle of advance device.(on request)
10. Checking the sealing of injection pump body
11. Install tube of auto-sucking oil supply can check on oil supply pump(including VE pump.)

we can made as your request. welcome to visit our website:

>>> Main products include:
1, Diesel engine parts (nozzle, plunger, delivery valve, head Rotor, injector, fuel pump and other accessories)

2,  Injection pump test bench

3,auto tools

4  Auto parts

5, special vehicles

6 , Turbocharger.......
     Production process using advanced computer control and digital display systems, production technology, strong technical force . High quality, high technical performance, with micro-controller and digital functions. Products are sold  more than 100 countries and regions of all world .
