EUS9000 HEUI AND EUI EUP TEST BENCH

EUS9000 HEUI AND EUI EUP TEST BENCH

· Function

Automatically test C7/C9/C-9,C3126/3408,Ford Power Stroke 6.0 and so on middle pressure common rail product.

Automatically test the injector seal, actuation point, pilot injection, medium speed, maximum load, the maximum test pressure is 2400 bar

Automatically test Bosch, Carter, CUMMINS, DDC, Delphi, Mercedes-Benz, Volvo, EUI/EUP and dual-valve E3,CUMMINS ISX and other special products

Automatically test oil return function of HEUI.

Support Fuel injector response time(BIP)function, can judge the EUI/EUP performance quickly and accurately.

· Technical parameter

1. Rated output power: 7.5KW ,11KW,15KW,18.5KW (on request)

2. Electronic power: 3PHASE 380V 50HZ OR 3PHASE 220V 60HZ

3. Motor speed: 0-4000RPM

4. Pressure adjustment: 0-2500bar

5. Fuel temperature: 40 ±2℃

6.Flow testing range:0-600ml/1000times

7.Flow measurement accuracy:0.1ml

8. Filter accuracy: less than 5um

9.Cooling system: fan or forced cooling

10. Fuel tank capacity: 60L

11.. Size: 1900MM * 900MM * 1500MM

9. Weight: 800kg

10. With 19-inch display

11. Adopt interference-free Logitech mouse
