C7 C9 C-9 INJECTOR AND PUMP TEST BENCH
- QINGDAO
- T/T Credit Card
You May Like
Product Details
| Brand Name | DONGTAI | Place of Origin | Shandong, China | |
| Model Number | HEUI | Power | Electronic |
Product Description
C7 C9 C-9 INJECTOR AND PUMP TEST BENCH
Application
The test bench is designed to test up to four HEUI injectors, which are equipped on the following engines:
Navistar T444E, as Ford 7.3L Power Stroke Engines
Navistar DT466E
Navistar I530E
Caterpillar 3126B laboratory test bench
Function
China HEU Itest bench Measurement fuel delivery of HEUI injectors
Sealing test for injector upper seat of the solenoid control valve HEUi Itest bench
Specification
Motor | 10HP motor |
Actuation Oil system | 0-300bar, |
Test Oil Supply | 0-4bar |
Test Oil Tank Capacity: | 40L |
Temperature control | Range: 10~50 Accuracy: +/- 1 Digital Display |
Injection Quantity Measurement | 150ML glass tube |
Main Features of HEUI Control Module
Adjustable Range of Injection Pulse Width | 0~6ms |
Fuel Delivery Measurement Counter Range | 1~9999 |
Simple, User-Friendly Display and Mini-Key Padc | |
