Help CenterXY-180 Hydraulic Water Well Drilling Rig Diamond Core Drilling Rig for Sale
Related Products
-
XY-8 Rock Core Drilling Rig Diamond Rock Boring Machine On PromotionUS$ 4000 - 6000MOQ: 1 Set -
XY-44A Hydraulic Pressing Machine Deep Water Well Drilling Rig for SaleUS$ 4000 - 6000MOQ: 1 Set
-
KY-200 Hydraulic Core Drilling Rig Geological Survey, Geophysical ExplorationUS$ 4000 - 6000MOQ: 1 Set
-
QTZ-1 High Quality Small and Light Soil Sample Drilling Machine, Shallow Soil Drilling MachineUS$ 4000 - 5500MOQ: 1 Set
-
QTZ-3 High Efficiency Portable Earth Drilling Rig Core Sample Drilling Machine ToolsUS$ 4000 - 6000MOQ: 1 Set
1.The main charateristic of XY-180 water well drilling rig
a.The XY-180 drill is designed on the basis of the XY-150 drill. It is a low speed and high torque portable drilling machine with oil pressure.
b.This drill is suitable for engineering geological survey of railway, hydropower, traffic, bridge, dam foundation and other buildings.
c.Geological core drilling and physical investigation.
d.Drilling holes for small holes and blasting holes.
e.A small water well drilled.
2.The technical parameter of XY-180 drilling rig
Drilling depth（m） |
180,150,120,90,70,30 |
Borehole diameter（mm） |
75,91,110,130,150,300 |
Maximum opening diameter（mm） |
375 |
drill pipe diameter（mm） |
42、50 |
Spindle Speed (r/min) |
71,142,310,620 |
SpindleStroke（mm） |
450 |
Upgrading Ability (KN) |
15 |
Diameter of steel wire（mm） |
12 |
Type |
gear pump |
Model |
YBC-12/80 |
Rated pressure (MPa) |
8 |
Rated speed (r/m) |
1500 |
Displacement（ml/r） |
8 |
Power supply |
ZS1115 diesel engine and 15kw motor |
