MBT-2500
Moving blade transmitter for fiber consistency from 1.5% – 8%
The MBT-2500 Active Blade Consistency Transmitter measures inline fiber consistency of pulp suspensions in the range of 1.5% – 8%. This moving blade transmitter works practically in every measuring position in pulping, bleaching and papermaking applications.
Low investment and lifecycle costs
It is pre-calibrated, durable and reliable where moderate accuracy is accepted
Insensitive to fiber composition, freeness, fillers, flow, air content or pressure
For closed loop consistency control
Fiber consistency measurement from 1.5% – 8%
Easy installation via a stud welded onto the pipe
Low investment and lifecycle costs
Applicable in the blow line after digester, in screening and washing stages, bleach plant till machine chest
Closed loop consistency control
The sensor is intended for inline installation into pulp- and papermaking process lines through a weld-in stud. It is rated for voltages of 100 – 240 VAC at 50 Hz / 60 Hz.
Measuring range
Shear force transmitter for 1.5% – 8% fiber consistency
Material
Wetted parts are made out of stainless steel, EN 1.4404
Process
Pressure PN25 (25 bar at 20°C or 360 psi at 68 °F)
Media temperature min. 10°C [50°F] to max.100°C [212°F]
Flow limits 0.1 – 5 m/s
