Resonant Breaker

Multi-head cement pavement crusher

PS400B/PS245

With the increasingly serious damage of concrete roads, there are more and more retrofitting projects for old cement concrete pavement all over the country.Because each place terrain is different, the structure of cement concrete pavement also is different, include the material of roadbed, the thickness of upper layer cement board to wait a moment.According to the damage degree of the pavement, the construction side in the old cement concrete pavement reconstruction construction requirements are not the same: some of the old pavement will be fully broken petrochemical, compaction after the use of the roadbed, on top of the asphalt layer or water stability layer;Some need to fully break the old road surface, clean up with excavators, this needs to break the cement plate particles up and down the better, in order to excavator construction.

The multi-hammer head cement pavement crusher is a kind of equipment which adopts advanced technology from abroad and is the first one made in China.By breaking the pavement with multiple hammerheads, small particles are formed in the old cement pavement, and the particles gradually increase from top to bottom to form a new roadbed after crushing.

The whole frame is adopted, the power is driven by cummins diesel engine, and the walking is driven by hydraulic and mechanical transmission, which can realize stepless speed change and smooth walking.The working device adopts hydraulic transmission, which can realize two kinds of manual and automatic control through the electric control of the control valve block. The remote control device can realize the driver's driving away from the machine, and can control the running speed of the crusher, the working state of the crushing hammer and the steering of the whole machine, so as to reduce the working intensity of the driver and improve the working comfort.

Equipped with special programmable controller for construction machinery, intelligent control system composed of display.The intelligent control system monitors and diagnoses the running state, and the running parameters are visually displayed by the color display.

Equipped with intelligent management system, to provide users with quality services.Through the intelligent management system real-time query equipment of all kinds of information, the operation time of the equipment, operating conditions, fuel consumption and other information for statistics and records, easy to work arrangement, cost control, maintenance and maintenance.

The application of intelligent control system and intelligent management system in crusher is the first in China.

Intelligent crusher becomes the ideal crushing equipment for cement pavement crushing petrochemical technology.

At present, it has been widely used in more than 30 provinces and cities, such as shandong, henan, hubei, sichuan, yunnan and so on.

Main features of multi-hammer head cement pavement crusher:

1. The microcomputer intelligent control belt fault diagnosis system was firstly adopted in China.

2. Initiated the adoption of intelligent management system in China.

3. Large crushing width, large impact depth, high operation efficiency and good crushing effect.

4. Simple construction, short renovation period of cement road surface, saving material cost and transportation cost, reducing project cost and realizing environmental protection.

● road breaking king first domestic road breaking precedent ● crack, broken petrochemical machinery has been serialized

● equipment ownership, engineering volume in the country both the first ● can be sold or rent, maximum to meet customer demand
