Help CenterReliable Quality Industrial Pneumatic Slide Gate Valve Epoxy Painting for Fly Ash System
Related Products
-
High Temperature Square Flange Type Knife Gate Valve With 2520 Stainless Steel for Solid ParticlesUS$ 100 - 5000MOQ: 1 Piece -
Square Flange Type Knife Gate Valve With 2520 Duplex Stainless Steel Body for High Temperature Solid ParticlesUS$ 100 - 5000MOQ: 1 Piece
-
2520 Stainless Steel Flanged Wafer Knife Gate Valve Wedge Gate Valve for Solid ParticlesUS$ 100 - 5000MOQ: 1 Piece
-
Double Actuator Square Knife Gate ValveUS$ 500 - 5000MOQ: 1 Piece
-
Square Type Slide Gate Valve With Double Hydraulic Actuator for Fly Ash SystemUS$ 500 - 5000MOQ: 1 Piece
FREE-VALVE’s Pneumatic Operation Slide Gate Valves are unidirectional knife edge gate valve used on industrial pipeline for on-off operation. It is a fabricated square or rectangular port low pressure for highly solid loaded fluids or solids,mainly used in bulk handling and silo outlet applications in industries.
Features:
1) The same construction as standard knife gate valve.
2) Body and gate in rectangular valve shape.
3) Same actuators and accessories as standard.
4) Rising stem tight model.
5) Square flange ends
Technical Specification:
1. Size Range:DN200xDN200.......DN1200xDN1200
2. Pressure Range: Class 150 /PN6 /PN10
3. Applicable Temperature: 0~120℃
4. Connection Type: Square flange
5. Sealing material: Rubber,Metal seal
6. Body Material: Carbon steel,stainless steel
7. Disc material:Stainless steel,carbon steel
Operating Mode: Hydraulic
Application:
FREE-VALVE’s Pneumatic Operation Slide Gate Valve is a powder, grain materials, small particle materials and the flow of materials or delivery of the main control equipment ,it was widely used in metallurgical, mining, building materials, food, chemical and other industries control the rapid flow of change or cut off.
Model：FRZS641H
Price:200-3000USD/set
Payment terms:TT,LC
Price terms:FOB,CIF,FCA,.CFR
Delivery time:30days
Origin:China
Wechat ID:FreeValve
Email:sales@free-valve.com
