Co1200/20 A12V190 Jichai Power Diesel Engine Used in Oil Field
- qingdao
- T/T L/C
- 7 days
You May Like
-
Jinan Diesel Engine Model G12V190PZL 1300r/Min Drilling Engine Used in Oil Field Chidong Jichai Brand
-
G6190 B6190 JICHAI JINAN CHIDONG BRAND MARINE ENGINE AND ENGINE PARTS
-
G12V190ZLC1 JDEC 190 SERIES MARINE ENGINE AND ENGINE PARTS
-
8V190 JDEC 190 SERIES MARINE ENGINE AND ENGINE PARTS
-
B6190ZLCZA-2R CHIDONG 190 SERIES 300KW MARINE ENGINE
-
B6190ZLCA-2 HC400 CHIDONG 190 SERIES 300KW MARINE ENGINE
Product Details
Brand Name | JICHAI | Place of Origin | China | |
Model Number | Z12V190B | Certification | iso9001 | |
After-sales Service Provided | Engineers available to service machinery overseas | Warranty | 1-3 months | |
Weight | 1212 | Dimension(L*W*H) | 112211221 | |
Condition | New | Fuel | Diesel | |
Start | Electric Start | Cold Style | Water-Cooled | |
Stroke | 4 Stroke | Usage | Other, land | |
Cylinder | Multi-cylinder |
Product Description
Model | Rated Power(KW/hp) | Rated Speed(r/min) | Specific fuel consumption(g/kw.h) | Specific oil consumption(g/kw.h) | Overall Dimension L*B*H(mm) | Net weigh(KG) | |
BG12V190ZL | 900/1500 | 800/1500 | ≤209.4 | ≤1.6 | 3160*1770*2400 | 5300 | |
BG12V190PZL | 900/1500 | 800/1500 | ≤209.4 | ≤1.6 | 4374*1740*2400 | 8100 | |
BG12V190ZL-3 | 810/1300 | 730/1300 | ≤209.4 | ≤1.6 | 3160*1770*2400 | 5300 | |
BG12V190PZL-3 | 810/1300 | 730/1300 | ≤209.4 | ≤1.6 | 4374*1740*2400 | 8100 | |
G12V190ZL | 900/1500 | 800/1500 | ≤209.4 | ≤1.6 | 2692*1560*2070 | 5300 | |
G12V190PZL | 900/1500 | 800/1500 | ≤209.4 | ≤1.6 | 3860*2040*2678 | 8100 | |
G12V190ZL-3 | 810/1300 | 730/1300 | ≤209.4 | ≤1.6 | 2692*1560*2070 | 5300 | |
G12V190PZL-3 | 810/1300 | 730/1300 | ≤209.4 | ≤1.6 | 3860*2040*2678 | 8100 | |
G12V190ZL-1 | 740/1200 | 660/1200 | ≤209.4 | ≤1.6 | 2692*1560*2070 | 5300 | |
G12V190PZL-1 | 740/1200 | 660/1200 | ≤209.4 | ≤1.6 | 3860*2040*2678 | 8100 | |
G12V190ZL-2 | 600/1000 | 540/1000 | ≤209.4 | ≤1.6 | 2692*1560*2070 | 5300 | |
G12V190PZL-2 | 600/1000 | 540/1000 | ≤209.4 | ≤1.6 | 3860*2040*2678 | 8100 | |
G8V190ZL | 600/1500 | 540/1500 | ≤213.5 | ≤2.7 | 1802*1560*2070 | 4300 | |
G8V190PZL | 600/1500 | 540/1500 | ≤213.5 | ≤2.7 | 3280*2040*2678 | 6750 | |
G8V190ZL-3 | 510/1300 | 460/1300 | ≤213.5 | ≤2.7 | 1802*1560*2070 | 4300 | |
G8V190PZL-3 | 510/1300 | 460/1300 | ≤213.5 | ≤2.7 | 3280*2040*2678 | 6750 | |
G8V190ZL-1 | 470/1200 | 425/1200 | ≤213.5 | ≤2.7 | 1802*1560*2070 | 4300 | |
G8V190PZL-1 | 470/1200 | 425/1200 | ≤213.5 | ≤2.7 | 3280*2040*2678 | 6750 | |
G8V190ZL-2 | 390/1000 | 350/1000 | ≤213.5 | ≤2.7 | 1802*1560*2070 | 4300 | |
G8V190PZL-2 | 390/1000 | 350/1000 | ≤213.5 | ≤2.7 | 3280*2040*2678 | 6750 | |
Main technical data | |||||||
No. and arrangement of cylinders:12,60.Vee | |||||||
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection | |||||||
Bore:190mm | |||||||
Stroke:210mm | |||||||
Total displacement:71.45(47.6)L | |||||||
Compression ration:14:1 | |||||||
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel) | |||||||
Starting method:Air motor or electric motor | |||||||
Lubricating method:Pressure and splash lubrication |
Jinan Guohua Green Power Equipment Co., Ltd. is located in the beautiful city of Quancheng----Jinan City. As an emerging development enterprise in Shandong Province and a green energy utilization enterprise.Jinan Guohua mainly engaged in the sales and maintenance of 190 series diesel generator sets and gas generator sets and their accessories.
After nearly ten years of continuous development, the company has formed a complete and mature sales and maintenance service system. At present, the company has set up a warehouse in Jinan and Xinjiang, covering an area of more than 1,000 square meters, with assets of 30 million yuan, more than 50 employees, including 20 technicians. At present, the company has obtained SGS general notary certificate,Jichai agent certificate.
The company's sales network has been continuously expanded. It has established stable supply and marketing relationships with 32 provinces, municipalities and autonomous regions in China, and has import and export rights. The products are sold overseas and have been sold to 20 countries including Asia, Africa, America, and the Commonwealth of Independent States. The above countries have established a solid cooperative relationship.
The company's main products:
I.: Jichai(chidong) / Shengdong 190 series gas engine parts, diesel engine parts.
II: Jichai(chidong) 190 series gas engine, diesel engine host.
III: 190 series engine overhaul and maintenance.
IV: the transportation of the power station.
Companies adhere to the "quality first, scientific management, customer first, integrity-based" purposes, in accordance with the "integrity, pragmatic, pioneering, innovative" spirit of enterprise, to meet the needs of users with first-class service.
Warmly welcome friends from all walks of life to review, cooperate and create brilliance together!
