Help CenterR2S175-AB56-01 Ebmpapst Centrifugal Fan R2S175-AB56-01 175 mm 230V EBM-PAPST Germany
Related Products
-
R3G133-RA01-03 Ebmpapst Centrifugal Fan EBMPAPST TYPE:R3G133-RA01-03 EBM FANUS$ 130 - 150MOQ: 1 Piece -
RL48-19-12-2 Ebmpapst Fan Centrifugal Compact Fan EBM-PAPST TYPE:RL48-19-12-2 EBM FAN DC 24VUS$ 20 - 26MOQ: 1 Piece
-
R2E220-RB06-01 Ebmpapst Centrifugal Fan EBM-PAPST Type:R2E220-RB06-01 EBM FAN 230V 220 mmUS$ 100 - 108MOQ: 1 Piece
-
R1G225-AF11-52 Ebmpapst Centrifugal Fan EBM-PAPST TYPE: R1G225-AF11-52 EBM FAN 48VUS$ 52 - 55MOQ: 1 Piece
-
D2D160-BE02-11 Ebmpapst Fan Centrifugal Fan EBM-PAPST TYPE:D2D160-BE02-11 380vUS$ 337 - 350MOQ: 1 Piece
Nominal data:
Type R2S175-AB56-01
Motor M2S052-CA
Phase 1~ 1~
Nominal voltage [V] 230 230
Frequency [Hz] 50 60
Type of data definition rfa rfa
Valid for approval / standard CE CE
Speed [min-1] 2350 2300
Power input [W] 53 51
Current draw [A] 0.33 0.29
Min. back pressure [Pa] 0 0
Max. ambient temperature [°C] 40 55
Technical features:
Leackage current
Size 175 mm
Operation mode S1
Direction of rotation Clockwise, seen on rotor
Mounting position Any
Insulation class "B"
Cable exit Axial
Condensate discharge holes None, open rotor
Bearing motor Ball bearing
Mass 0.9 kg
Material of impeller PA plastic 6, fiberglass-reinforced
Motor protection Thermal overload protector (TOP) wired internally
Product conforming to
standard
CE; EN 60335-1
Surface of rotor Coated in black
Number of blades 7
Type of protection IP 20
Protection class I
Max. permissible ambient
motor temp. (transp./ storage)
+ 80 °C
Min. permissible ambient
motor temp. (transp./storage)
- 40 °C
Approval CCC; GOST
