ccs ah36 gl ah36 steel plate
AH36 steel is a kind of steel for shipbuilding and platform. AH36 steel plate is the high tensile strength steel. BBN steel passed classification societies certification of ABS, LR, BV, DNV GL, RINA, NK, CCS, KR, RMRS.
AH36 steel plate data sheet:
AH36 steel plate Specification |
According to client's need |
|
| Technique | Hot rolled, TMCP |
|
| Density | 7.85 g/cm ³ |
|
| Additional Condition | Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, UT, The Third Party Test (such as SGS Test) |
|
AH36 steel plate chemical composition:
| C max | Si max | Mn | P max | S max | Al Min. | Cb | V | Ti max. | Cu max. | Cr max. | Ni max. | Mo max. | N max. |
| 0.18 | 0.10-0.50 | 0.90-1.60 | 0.035 | 0.035 | 0.015 | 0.02-0.05 | 0.05-0.10 | 0.02 | 0.35 | 0.20 | 0.40 | 0.08 | - |
AH36 steel plate mechanical property:
| Grade | Mechanical Property | Charpy V Impact Test | |||||
| Thickness | Yield | Tensile | Elongation | Degree | Transverse | Longitudinal | |
| AH36 | mm | Min Mpa | Mpa | Min % | 0 | J | J |
| t≤50 | 355 | 490-620 | 19% | 24 | 34 | ||
50| 355 |
490-620 |
19% |
27 |
41 | | ||
70| 355 |
490-620 |
19% |
34 |
50 | | ||
AH36 steel plate application:
AH36 steel plate is used primarily in shipbuilding, ship repair and other marine applications. The high strength characteristics and so on properties of AH36 steel plate meet the structural requirements of ships, barges, and other types of marine equipment.
