About Us
The aluminum liquid distribution bag produced by Shandong Ningjin Bohan Machinery Co., Ltd. has been specially selected, designed and woven to ensure that the yarn and mesh of the distribution bag are uniform and prevent the pressure or flattening caused by the contact Deformation, especially suitable for splitting and filtering of molten aluminum in large furnace slabs. The company has passed ISO9001 certification. Each batch of products is tested to check its burning loss, stiffness and mesh size to ensure the stability of product quality.
Paramter
Type |
Common |
Standard |
High Purity |
Zirconia |
|
Classification temperature (°C) |
1100 |
1260 |
1260 |
1400 |
|
Working Temperature (°C) |
< 1000 |
1050 |
1100 |
1350 |
|
Color |
White |
Pure white |
Pure white |
Pure white |
|
Density (kg/m3) |
96/128/160 |
96/128/160 |
96/128/160 |
128/160 |
|
|
Shrinkage on heating (%) (24 hours, density as 128/m3) |
-4 |
-3 |
-3 |
-3 |
|
Thermal conductivity by different temperature (w/m.k) (density as 128kg/m3) |
0.09(400°C) |
0.09(400°C) |
0.09(400°C) 0.16(800°C) |
0.16(800°C) |
|
Tensile strength (MPa) |
0.04 |
0.04 |
0.04 |
0.04 |
|
|
Chemical composition (%) |
AL2O3 |
44 |
46 |
47-49 |
39-40 |
AL2O3+SiO2 |
96 |
97 |
99 |
- |
|
AL2O3+SiO2+ZrO2 |
- |
- |
- |
99 |
|
ZrO2 |
- |
- |
- |
15-17 |
|
Fe2O3 |
<1.2 |
<1.0 |
0.2 |
0.2 |
|
Na2O+K2O |
≤0.5 |
≤0.5 |
0.2 |
0.2 |
|
Application:
1.Industrial furnace, heating devices, high temperature pipe wall linings
2.High tempeture boilers, steam turbine and Nuclear power thermal insulation
3.Chemical industrial high-temperature reaction equipment and heating equipment wall linings
4.High building fireproof and thermal insulation
5.Furnace door and roof thermal insulation
6.High temperature filter materials
