Δ STANDARD CONFIGURATION
1) Powered by brand new original CUMMINS water cooled diesel engine.
2) Brand new STAMFORD, LEROY SOMER or GENLITEC single bearing 3 phase alternator with IP23 and H insulation class.
3) Original CUMMINS 50ºC radiator with engine driven fan mounted on skid.
4) Delixi or Chint branded case circuit breaker mounted.
5) Heavy-duty fabricated steel based frame with built-in fuel tank for at least 8 hours continuous running.
6) Complete set mounted on a based frame with anti-vibration mountings.
7) Industrial 9 dB muffler exhaust system with blexible connects and bellows.
8) Based frame with fuel, oil and coolant drain cocks for easy maintenance.
9) 12/24V DC electric start system with free maintain battery & smartgen brand battery charger.
10) Set mounted automatic control panel, with SMARTGEN brand AMF controller module for automatic start & stop.
11) Test report of generator, set of drawings and manuals.
12) CE, ISO9001 approved
Δ TESTING ITEMS
GENLITEC POWER provides a full line of brand new and high quality products.
Each and every unit is strictly factory tested before shipment.
1) Parts faults testing
2) Fuel tank pressure testing
3) Bolt tightening torque testing
4) Painting thickness testing
5) Voltage bearing and insulation testing
6) Noise testing
7) Loading Testing: 25%, 50%, 75%, 100%, 110% load to check verify that all control systems, alarm and shut-down protection.
Δ OPTIONAL SUPPLY
1) Weatherproof canopy / Soundproof canopy / Trailer-mounted
2) Engine / Alternator Pre-heaters
3) Auto load sharing & synchronization panel
4) Build-in ATS (Auto start & stop Main Failure (AMF)
5) Large 12/24 hours fuel tank
6) Power output sockets
Δ GENSET SPECIFICATION
| GENSET MODEL | GPC150S5 |
| Prime power (50Hz) | 120KW/150KVA |
| Standby power (50Hz) | 132KW/165KMVA |
| Frequency/Speed | 50Hz/1500rpm |
| Voltage | 220V/380V |
| Phase | Three phase, Four wires |
| Manufacturer | Genlitec (Fuzhou) Power Equipment Co., Ltd. |
| Model | DCEC 6BTAA5.9-G12 |
| Engine speed | 1500rpm |
| Engine power (Gross) | 155KW/207HP |
| Number of cylinders | 6 |
| Cylinder arrangement | Vertical in-line |
| Cycle | 4-troke |
| Aspiration | Natural |
| Combustion system | Direct injection |
| Compression ratio | 17.3:1 |
| Bore and Stroke | 102 x 120mm |
| Displacement | 5.9 Liters |
| Fuel system | Pump |
| Cooling system | Water cooled |
| Speed-droop | 5% |
| Starting system | DC24V |
| Model | GENLITEC S274G120 (STAMFORD or LEROY SOMER alternator as options) |
| Output power | 120KW/150KVA |
| AVR model | SX460 |
| Number of phase | 3 |
| Power factor (Cos Phi) | 0.8 |
| Altitude | ≤1000m |
| Over speed | 2250RPM |
| Number of pole | 4 |
| Exciter type | Shunt |
| Insulation class | H |
| Voltage regulation | ±0.5% |
| Wave form: NEMA = TIF | <50 |
| Wave form: I.E.C = THF | <2% |
| Bearing | Single |
| Coupling | Direct |
