Prefabricated steel space frame structure airport terminal construction
- 20000 Ton / Tons per Month
- Lianyungang, Qingdao, Shanghai for Prefabricated steel space frame structure airport terminal construction
- T/T L/C D/P D/A
- 45 days
Product Details
Brand Name: | LF-BJMB | Place of Origin: | China | Model Number: | LF-AC0358 |
Material: | Steel |
Product Description
Prefabricated steel space frame structure airport terminal construction
Specification | Structure type: | Light steel |
Design standard: | AISI ASTM BS DIN GB JIS NSCP | |
Length: | With customer’s requirement | |
Width: | Single span, double span, long span | |
Height: | With customer’s requirement | |
Components | Bolt ball: | Steel 45#, epoxy zinc primer with PU paint |
Column: | Q235, Q345 welded H section steel | |
Beam: | Q235, Q345 welded H section steel | |
Tube: | Steel Q235, epoxy zinc primer with PU paint | |
High strength bolt: | Cr 40, electroplating | |
Sleeve: | Steel Q235 & 45#, electroplating | |
Purlin: | Q235 C channel or Z channel, galvanization | |
Roof&Wall panel: | Sandwich panels, color steel sheet, day light sheet-FRP sheet |
My friends, you are welcome to inquire on our product and prices, and any inquiry
should be replied within 24 hours.
LF Group Advantages— Large Span Space Frame Expert
Strong Production Capability
Production Lines: 9 production lines of light steel,heavy steel,space frame and tube truss.
5 production lines of color steel plate,curtain wall and other envelope structures.
Advanced Production Equipment
Advanced Coating System
Our experience has led to continuous technology and process improvements. The result is the finest epoxy coating available in the space frame industry.
The coating system is derived from years of in-field experience and performance data.
Professional Design
We are capable of designing as following standards and products:
Choose you want, convenient for yourself
Packing | Depends on the size of space frame and material. For the convenience and safe in the delivery, Special export packing. |
Shipping |
30-60 days after construction drawing is confirmed by client. |
Welcome to connect with us by details below
Information |
Xuzhou LF Engineering & Construction Co., Ltd. Tel: +86 516 85950258 Fax: +86 516 85950278 Website:
|
FAQ
Q1:Can I have a sample for testing?
A:Of course, we think samples are very important. You can also buy them from anywhere. But we believe that our cargoes will better then any others.
Q2:Can I have a visit to your factory before the order?
A: Why not? welcome to visit our factory. You can fly to Xuzhou guanyin Airport.We will pick you up in the airport.
Hotel booking service is available .
Q3. Do you supply installation service?
A: Yes,we do. But you will pay for our professional fee if we install in your local place. Then we will send engineers to supervise it.
Question 4: How long can the space frame be used?
A: The use life of the main structure is the designed used life, that is 50-100 years (standard request of GB).
Question 5: How long is the use life of roof cover?
A: The use life of PE coating is usually 10-25 years. The use life of roof day-lighting panel is shorter, usually 8-15 years.
Question 6: What is the anti-rust treatment for space frame?
A: Anti-rust treatment of steel space frame
Normal anti-rust paint
Anti-rust paint with epoxy zinc primer
Hot-dip galvanization
Hot-dip galvanization+PU finish
Powder coating.
Stainless steel space frame: No.301/304/316 stainless steel space frame.
Question 7: What are the advantages of space frame?
A1: The span of space frame can be very large without columns in the middle to support the whole structure, so space frame structure is suitable for buildings covering large area.
A2. Cost of space frame
Generally speaking, if span≥40m,the cost of space frame is lower than the other structures.
If span<40 & ≥20m, the cost of space frame is almost same to other steel structures.
If span<20m, the cost of space frame is higher than other structures.
3. Space frame structure is more secure than other traditional structures.
4. Space frame has excellent seismic performance.
5. Space frame is easy to install.
6. Space frame structure is easy for transportation, as the size of components are small.
7. Space frame can be used to all kinds of building.
8. Space frame is suitable for factory production.
