US$ 3.7 - 8
MOQ: 5000 Pieces
Key Specifications
Get Latest Price
Brand Name:
Casic Motor
Place of Origin:
China
Model Number:
ZYT28T-CS-025
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
7 days
Related Products
-
24V DC Motor With Speed Control 2400 RpmUS$ 4 - 9MOQ: 5000 Pieces -
24V Gearbox Motor for Vending MachineUS$ 3.5 - 8MOQ: 5000 Pieces
-
Fan Brushless DC Motor With High SpeedUS$ 6.5 - 10.5MOQ: 5000 Pieces
-
9V Linear DC Motor With Gear ReductionUS$ 3.8 - 8.2MOQ: 5000 Pieces
-
Water Pump Motor for DishwasherUS$ 16.8 - 28.2MOQ: 5000 Pieces
Brand Name
Casic Motor
Place of Origin
China
Model Number
ZYT28T-CS-025
Type
Gear Motor
Certification
CCC, CE, ROHS, UL, VDE
Torque
0.8 N.m
Usage
Other, Fan, Home Appliance, Vending Machine
Construction
Permanent Magnet
Efficiency
IE 1
Protect Feature
Drip-proof
Voltage(V)
24VDC
Output Power
5.28W
Continuous Current(A)
0.22A Max
Speed(RPM)
20 rpm ± 2rpm
Commutation
Brush
Technical Data
Model | ZYT28T-CS-025 | Direction of Rotation | CCW |
Rated Voltage | 24 VCD | Rated Current | 0.22A MAX |
No Load Current | 0.12A MAX | Rated Speed | 20 rpm ± 2 |
No Load Speed | 30 rpm ± 3 | Noise | 60 dBA MAX |
Rated Torque | 0.8 N.m | Gear Ratio | 270.9:1 |
