P6 Outdoor TV LED Display with Iron Cabinet for Roof Building Fixed Installation
- 100 Square Meter / Square Meters per Month
- Shenzhen
- T/T Credit Card
- 15 days
You May Like
-
LED TV Display P5 with 960x960mm LED Cabinet for Outdoor Advertising Screen Showing
-
4K P2.5 Indoor Rental LED Screen with Die-casting Aluminium Cabinet
-
P2.976 Indoor Full Color LED Screen with Die-casting Aluminum Cabinet for Rental
-
P3.91 Indoor 90 Degree Installation High Refresh Indoor Mobile LED Screen for Sound Events
-
High Quality P10 Indoor Full Color LED Screen for Fix Installation
-
P6 Indoor Full Color LED Screen with Steel Cabinet for Fix Installation
Product Details
Place of Origin | China |
Product Description
P6 Outdoor TV LED Display with Iron Cabinet for Roof Building Fixed Installation
Permanent Fixed LED Display
With Kinglight or Nationstar led lamp as basic, to ensure the quality to the customer, which can ensure the long lifespan up to 2 to 5 years. P6 outdoor fixed led display can be make with 1/8 scan and 1/4 scan, to be provided with different brightness to 5000nits or 5500nits for the outdoor application.
Features of P6 Outdoor LED Digital:
1. High brightness: With Kinglight and Nationstar, to ensure the led lamp quality and it’s brightness, which is up to 5000-5500nits.
2. Large viewing angle: Horizontal with 140degree, vertical with 120 degree, suit for outdoor large place environment.
3. Iron cabinet and aluminum cabinet available according to the led screen installed environment,cabinet size can be customized.
4. High refresh rate, up to 1920-3840Hz, to ensure the image quality.
5. Hand holder and side lock design for the led cabinet, easily to carry the led cabinet and assemble them one by one.
6. High heat dissipation: With two or four fans to fix in the back door, keep the led cabinet can be used in the high temperature application.
7. Front service & rear service are available, can fix in any places.
8. Long life-span up to 2-5 years.
Specification of SMD Outdoor LED Display:
Parameter Technical of P6 Outdoor LED Video Wall Supplier | ||
Item | Model | Parameter |
LED Module Info. | Pixel Pitch | P6 Outdoor Fixed LED Panel |
LED Lamp | SMD2727 | |
IC Driver | MBI5124/MBI5051B/MBI5253 | |
LED Module Size | 192*192mm | |
LED Module Resolution | 32*32dots | |
Color Temperature | 3000-9000K | |
Drive Mode | 1/8 scan & 1/4 scan | |
LED Cabinet Info. | Cabinet Size | 960*960*120mm |
Cabinet Resolution | 160*160dots | |
Cabinet Material | Iron or Aluminum Cabinet | |
LED Module Quantities | 5*5=25pcs | |
Cabinet Net Weight | 45kg/pc | |
IP Grade | Waterproof IP65 | |
LED Display Info. | Best Viewing Distance | 6m-100m |
Viewing Angle | H: 140°/ V:120° | |
Pixel Density | 27777dots/㎡ | |
Brightness | 5000-5500nits | |
Max.Power Consumption | 664W/㎡ | |
Ave.Power Consumption | 299W/㎡ | |
Refresh Rate | 1920Hz-3840H, can be adjusted | |
Control System Info. | Operating System | WIN98/2000/NT/XP |
Control Method | Synchronous display with control PC by DVI or Asynchronous with Wifi/4G/USB | |
Control System | Linsn, Nova-star, Colorlight or as you required | |
Display Content | Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc. | |
Frame Frequency | 50Hz or 60Hz | |
Transmission Distance | Multi mode fiber<500m, single mode fiber <30km,internet cable<100m | |
Operation Info. | Working Temperature | -20℃--+60℃ |
Storage Temperature | -30℃--+80℃ | |
Input Voltage | AC110V/AC220V | |
Humidity Environment | 10%-95% | |
Lifespan | 100,000hours | |
MTBF | 10,000hours | |
Certificate | CE, CCC,FCC,ROHS,ISO9001 |
