Heavy and High Speed RD-1325 Linear Type ATC CNC Router Machine 3 Axis Milling Machine

Name: Heavy and High Speed RD-1325 Linear Type ATC CNC Router Machine 3 Axis Milling Machine
Brand: RAPID
SKU: 161852291
Availability: InStock

Heavy and High Speed RD-1325 Linear Type ATC CNC Router Machine 3 Axis Milling Machine thumbnail-1

Heavy and High Speed RD-1325 Linear Type ATC CNC Router Machine 3 Axis Milling Machine thumbnail-2

Heavy and High Speed RD-1325 Linear Type ATC CNC Router Machine 3 Axis Milling Machine thumbnail-3

Heavy and High Speed RD-1325 Linear Type ATC CNC Router Machine 3 Axis Milling Machine thumbnail-4

Heavy and High Speed RD-1325 Linear Type ATC CNC Router Machine 3 Axis Milling Machine thumbnail-5

Heavy and High Speed RD-1325 Linear Type ATC CNC Router Machine 3 Axis Milling Machine photo-1

Heavy and High Speed RD-1325 Linear Type ATC CNC Router Machine 3 Axis Milling Machine photo-2

Heavy and High Speed RD-1325 Linear Type ATC CNC Router Machine 3 Axis Milling Machine photo-3

Heavy and High Speed RD-1325 Linear Type ATC CNC Router Machine 3 Axis Milling Machine photo-4

Heavy and High Speed RD-1325 Linear Type ATC CNC Router Machine 3 Axis Milling Machine photo-5

US$ 17000 - 17200 MOQ: 1 Set

Key Specifications

Get Latest Price

Brand Name:

RAPID

Place of Origin:

China

Model Number:

RD-1325

Contact Supplier Request Quote Chat Now

Jinan Rui Ye-Feng CNC Equipment Co.,Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

QING DAO

Delivery Detail:

30 days

Product Details
Company Profile
Contact Us

Brand Name RAPID

Place of Origin China

Model Number RD-1325

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Warranty 14 months

Condition New

CNC or Not CNC

Overview

RD-1325 Linear type ATC CNC Router machine is build with thick steel construction, superior components are adopt to keep high quality, such as Italy HSD spindle, Japan SHIPMO reducer, Japan YASKAWA servo motor, German WNH rack and pinion,etc. So machine’s Max. Speed can up to 45-50m/min.

Linear type ATC is included, 8 position tool holder rack is mounted on the rear of working table, so machine can complete the most complex multi tool tasks effectively.

It is usually applied in wood door furniture industry for a series of complicated processing including cutting, carving, drilling, edge milling and hollow-out engraving.

Advantages

1. Heavy duty machine structure guarantee solidity and absence of vibration

so machine’s processing precision will be highly improved.

2. 9kw(12HP) large power air cooling spindle is come from Italy HSD company.

The programmable speed can up to 24000RPM

3. Japanese AC servo motors and drives

The closed-loop control of position, speed and torque is realized, improving precision.

Rotated speed can up to 3000RPM, good high speed performance

Heat and noise significantly reduced

Motor on Z axis has brake system to prevent working table damaged because of spindle falling suddenly

4. Linear type ATC is included

8 position tool holder rack is mounted on the rear of working table, so machine can complete the most complex multi tool tasks effectively.

Application industry

Woodworking Industry:

Furniture like solid wood door, PVC wood door, cabinet, window; music instrument; wooden artware

Decoration Industry:

Art model, Wall Art, Relief engraving, wave board, gift wrapping, sports equipment, electrical cabinets panels,etc.

Advertisement:

Acrylic, double color board, PVC, MDF, ABS,aluminum-plastic board, artifical stone, organic glass, density board, matrix, character, signs, trademarks, soft metal like aluminum, cooper,etc.

Configuration

Travelling size	13002500300mm
Spindle power	9KW Italy HSD air cooling
Rotating speed	24000RMP
Re-positioning precision	±0.003mm
Transmission	X/Y rack and pinion drive, Z ball screw drive
Rack Guide	Germany WMH rack gear
Guide rail	Taiwan HIWIN square rail
Work Surface	Vacuum absorption working Table
Travelling speed	45-50m/min
Working speed	20-25m/min
ATC Tool magazine	Linear type 8 tools
Driver motor	Japan Yaskawa servo system
Frequency inverter	Taiwan delta
Working Voltage	AC380/3PH/50HZ
Command Language	G cord.u00.mmg*plt, HPGL
Interface	USB and Ethernet
Controller	Taiwan Syntec system
