STANDARD TANK CONFIGURATION&SPECS
Material: SUS 304 S/S
Volume: 2000L effective,2670L total volume, 25% head space, without domed head space
Tank working pressure: 2.5bar
Jacket working pressure: 1bar
Inner tank thickness: 3mm, outer cladding: 2mm
Polyurethane insulation, thickness: 100mm, side and bottom insulated
Dimple plate cooling jacket
Cooling stage: cylinder and cone
Since temp control stage
Exterior: stain removed, and brightened on regular margin
Interior surface: Polished, and welding joint acid cleaned
Roughness: 0.4um
Domed top, 60 degree cone angle
4 pcs stainless steel leg, with adjustable leg bolt
Top fittings: CIP arm, spray ball, PVRV
Side fittings: Glycol inlet/outlet, thermo well, sample port, manway (side)
Bottom fittings: Drain valve, beer racking arm, with carbonation stone
CIP arm including pressure gauge and pressure regulator
Mechanical pressure valve mounted with CIP arm
Top dry hopping port
Material inlet/outlet with DIN, glycol line with TC
Fittings quantity:
4* butterfly valves (drain outlet, beer outlet, 2 for CIP arm)
1*sample valve
1* breathe valve on tank top
1*pressure regulation installed with CIP arm
1*CIP arm
1* pressure indicator
1* temp sensor
1* solenoid valves
1* check valve (part of glycol cooling line)
