Supermendur, HiperCo50
- Shanghai
- T/T
You May Like
Product Details
| Brand Name | Brilliance | Place of Origin | China | |
| Model Number | BL-0144 | Type | Nickel Wire | |
| Application | Electronics | Grade | FeCo50V2 | |
| Powder Or Not | Not Powder |
Product Description
High Saturation magnetic induction soft magnetic alloys
Note:
Hiperco 50A alloy is a soft magnetic alloy which has been used primarily as magnetic core material in electrical core material in electrical equipment requiring high permeability values at very high magnetic flux densities. The magnetic characteristics of this alloy permit weight reduction, reduction of copper turns, and insulation in the end product when compared to other magnetic alloys having lower permeabilities in the same magnetic field range.
Relative Grade :
| Grade | U.K. | Germany | U.S.A. | Russia | Standard |
| 1J22 | Permendur | Vacoflux 50 | Supermendur HiperCo50 | 50КФ | GB/T15002-1994 |
Grade and Chemical Composition
| Grade | Chemical Composition (%) | |||||||||
| C≤ | Mn≤ | Si≤ | P≤ | S≤ | Cu≤ | Ni≤ | Co | V | Fe | |
| 1J22 | 0.04 | 0.30 | 0.30 | 0.020 | 0.020 | 0.20 | 0.50 | 49.0～51.0 | 0.80～1.80 | Balance |
Physical Property
| Grade | Resistivity /(μΩ•m) | Density/(g/cm3) | Curie point/°C | Magnetostriction Cofficient/(×10-6) | Tensile Strength,N/mm2 | |
| Unannealed | Annealed | |||||
| 1J22 | 0.40 | 8.20 | 980 | 60～100 | 1325 | 490 |
