Function:
1. To test if the CR injector is still function, to connect a CR injector to a high pressure fuel source by a high pressure fuel line and to the CR tester by harness. The tester is set to continuous is injection mode. The CR injectors in normal condition, if it is capable to inject fuel under the driving signals by the tester.
2. To test injector spray atomization, to connect a CR injector to a high pressure fuel source by a high pressure fuel line and to the CR tester by harness. The tester is set to single injection mode to allow observing the nozzle spray pattern to judge if the nozzle is normal or orifice plugged.
3. Checking the injection return oil and injection oil.
4. With ultrasonic cleaning tester to clean the nozzle.
Main Voltage (Vac) |
220V |
Main Frequency (Hz) |
50/60 |
Max Filling Volume per Tank (lit./gal) |
2 |
Input System pressure (bar/psi) |
0-10/0-145 |
System Build-up Pressure (bar/psi) |
0-1800bar/0-26100 psi |
It is used to test the common rail injector, and it also can clean the common rail injector by Ultrasonic Cleaning Instrument.
Technical data:
1. High pressure 0-1800bar
2. Check the injector starting pressure
3. Assessment of the injector spray fog quality
4. Inspection of the injector spray oil range
5. Check of the injector seal and angel
6. Check of the injector oil flow
7. The parameter of common rail injector (fuel spray counts, frequency, pulse width, Voltage) can be set willfully.
a: injectors
b: glass tubes for injection oil
c: glass tubes for return oil
d: oil pressure gauge
e: leakage oil pressure valve
f: air pressure gauge
h: air source switch
g: adjusting pressure valve
i: common rail simulator
k: ultrasonic oil tank
j: air source throttle
n: leakage oil valve( switch) for injection oil
m: leakage oil valve ( switch) for return oil
L. protection cover
R: injector adaptor
S: air source plug for connecting air compressor
T. Power plug
We aimed at one hundred percent of the customer satisfied, committing to continuously improve
the service ability and level. We provide a good guarantee for our customers, In order to provide
comprehensive quality services for customers more professionally and effectively.
1. We will be a comprehensive service, tracking goods, welcome to your any feedback.
2. The problem for you, we provide professional technical guidance services.
3. More professional service.
Beijing Global Auto Parts Co., Ltd. is one of the leading trade companies in China and one member of Chinese Commercial Vehicle Parts Market Federation, specializing in commercial vehicle and diesel engine parts for 7 years.
We have export business with many customers from all over the world, mainly including the Middle East, Europe, Africa, and Southeast Asia. Meanwhile, we have established long-term partnership with over 20 leading diesel engine parts manufacturer in China with effective quality insurance system.
Our products include nozzles, elements, delivery valves, injectors, pistons, piston rings, cylinder blocks, cylinder heads, crankshafts, camshafts, turbochargers, fuel injection pumps and feed pumps. At the same time, we have good relation with main Chinese auto makers and our supplier, including FAW, DFM, CNHTC (STEYR, HOWO), FOTON (FOTON, AUMAN), SHANXI (SX, STEYR), YUCHAI, WEICHAI and DCEC. With their assistance, we can provide pure China made auto parts and components.
