Lsaw Carbon Steel Pipe A671 Gr.b 60 Cl32 Petroleum Gas Oil Seamless Tube

Product Name	seamless steel pipe / welded steel pipes
Material	Carbon , Alloy , Stainless . Nickel Alloy , Monel
Color	Black Steel
Standard	Production in acc: EN, ASTM, ASME, API, GOST, JIS, DIN, BS, NF A, UNI, STN, ČSN, PN – H,
Grade	API 5L  B, X42, X52, X60, X65, X70, X80
Brade	OK
Thread	NPT
Used	Steel tube for pressure appliances § for room temperature pressure use   tubes for low temperature pressure use § boiler tubes for high-pressure use   fine grain steel tubes for pressure equipment

LSAW steel pipe (Longitudinal double submerge arc welding steel pipe/DSAW steel pipe) is one kind of the SAW pipes,it is made of steel plates of hot rolled by JCOE or UOE forming technology. Our company usually produce the pipes by JCOE technology,the JCOE means the forming process, as J shape firstly, then C shape, and then O forming,E forming process at last, while inner & outside welding and cold expansion after welding. Compared with UOE LSAW pipes, our productive line could produce more sizes,OD406mm-1620mm, pipe length: 2m-18m,the thcikness from 6.35mm-60mm and our LSAW pipes has its superiority:

Longitudinal double submerge arc welding steel pipe(LSAW steel pipe) is made of steel plates of hot rolled by JCOE and UOE. JCOE means the forming process, as J shape, C shape, O forming, inner&outside welding and cold expansion after welding. It only has one straight seam on the pipe body.

1. Feature: Large diameter,thick wall,high pressure&low temperature resistance

2. Test: Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength,Yield strength, Elongation), Technical Properties (Flattening Test, Blow Test, Impact Test,DWT test), Exterior Size Inspection, Hydrostatic Test, X-ray Test,UT test.

3.Application:The base metal and weld metal were tested according to the pipe specification API SPEC 5L PSL1, Widely used for liquid delivery,such as oil,gas,water and seashore,ground constructions
