Direct Sales of Brazilian Metal Laser Welding Machine Manufacturers

Product application:

Optical fiber transmission is easy to realize automation. In the battery industry, it industry, electronic devices, optical communication industry, sensor industry, hardware industry, auto parts industry, mold repair industry, jewelry welding industry, glasses industry, porcelain teeth, solar energy industry, electric heating industry / thin-walled materials, precision parts welding, it can realize spot welding, butt welding, stack welding, seal welding And so on.

working principle:

YAG laser welding machine, laser wavelength 1064nm, its output power is large, stability is good, welding line is uniform, fine; can weld a variety of metal materials. YAG laser uses high-power LED as the energy source, Nd: YAG as the working substance, and the high-power LED sends light with wavelength of 1064nm to promote the energy leap of the working substance, so as to release the laser. After amplifying the released laser energy, x, y, Z, d control the movement of the beam, so as to make the joint welding closer.

Performance features:

⊙ fiber laser welding machine realizes the flexible output of laser, which can work with the assembly line or be used independently.

⊙ laser welding has small heat affected area, rapid heating concentration and low thermal stress, so the deformation of the welded product is small and does not affect other properties of the product. ⊙ energy is controllable, output power is stable, thin-walled metal will not be welded through.

⊙ small focus light class, high power density, high melting point, high strength metal and alloy materials can be welded.

⊙ the laser beam energy can be adjusted, the moving speed can be adjusted, and the welding of various materials can be realized.

⊙ equipped with high-definition CCD system, which can monitor the welding seam in real time.

⊙ it can realize full-automatic welding or semi-automatic welding according to the user's requirements, with simple operation and greatly saving the user's labor cost.

⊙ it can be used with manipulator.

Software functions:

⊙ able to receive various CAD format files

⊙ automatically generate all kinds of points, circles, lines, curves, squares, polygon patterns

⊙ support flight welding

⊙ support rotary welding

⊙ support large area XY platform automatic welding

Technical parameters:

Model

Technical parameters hj-gq tc-hj-gq

Output laser power: 200w-300w-400w, 500w-800w-1000w

Laser wavelength: 1064um 1064um

Maximum pulse energy: 80J, 100J

Maximum peak power: 7KW 9.9kw

Pulse width: 0.5-20ms

Pulse repetition frequency: 0-100hz

Continuous pulse width per unit time: 100ms / S

Splitting mode: energy splitting or time splitting

Closed loop feedback control mode: any waveform real-time control power negative feedback

Energy volatility<

Nonuniformity of energy distribution<

Positioning mode: red light

Power supply requirements: AC380V

Power consumption of the whole machine: 8kw, 16kw

Cooling mode water cooling

Service commitment:

Shenzhen Tiance Laser Technology Co., Ltd. adheres to customer-centered, providing your company with perfect pre-sales and after-sales services such as installation, debugging, training and maintenance.

1. Pre sales service: before signing the contract, the company provides customers with various production process plans, technical consulting, sample samples, equipment selection and other services for laser equipment.

2. Installation and debugging: according to the contract, our company will safely transport the equipment to the installation site designated by the user within the specified time free of charge, and send the technical service engineer to install on site. When the spare parts for installation and commissioning are basically available, the technical service engineer will complete the installation and commissioning of the machine for trial use within 1-2 days, and ensure that the installation and commissioning site environment is tidy, clean and orderly.

3. After sales training: the company provides free technical training. After the installation and commissioning, technical training shall be provided to the buyer's operators at the buyer's site or the seller's domestic training and maintenance center until the operators can basically use the equipment. The main training contents are as follows:

⊙ use training of common drawing software;

⊙ training on operating procedures of switching machine;

⊙ significance of panel and software control parameters, training of parameter selection range;

⊙ basic cleaning and maintenance of the machine;

⊙ common hardware troubleshooting;

⊙ precautions in operation:

In addition to this, it also provides users with technical support for the products they produce.

The company undertakes:

⊙ the equipment is free of charge for one year, and the maintenance items are complete machine maintenance and lifelong maintenance. (welding consumables are not covered by warranty)

⊙ free technical consultation, software upgrade and other services.

⊙ provide regular technical services to deal with abnormal conditions of the machine.

⊙ response time of customer service is within 24 hours.

⊙ after the expiration of the warranty period, it still provides a wide range of hardware and software support and services.
