small round bottle wrap around side labeling machine

small round bottle wrap around side labeling machine

1) Applicable to label whole curved surfaces or half curved surfaces on rotundities that can't stand on their on their own fet with short diameter;
2) Advanved touch human-compater interface which is easy and intuitionistic to operate and has complete functions including abundant online help;
3) The design of special tilting loading material method and conveying by idler wheel makes the objects to labe to be located automatically;
4) Automatic photoelectric detection functions,such as cancelling labeling without objects there,stopping running or raising an alarm without labels to use to avoid omitting or wasting lables;
5) Simple and compact machine construction that is easy to operate and maintain;
6) Well-knowen motor drive is matched with the complete machine that ensures a stable and reliable label-feeding speed

Technical Parameter:
Labeling Size:(L)more 20mm (W)15-135mm
Rolling inside diameter:76mm
Product Size:(D)20-150mm (H)Less 200mm
Rolling outerside diameter:350mm
Labeling Precision:+-1mm
Power Supply:AC220V 50Hz 3kW
Labeling Speed:40-200(pcs/min)(relate to material and label size)
Machine Size:(L)2000*(W)1700*(H)1500mm
