Power Electronic Capacitor AEV E-Viecle

Power Electronic Capacitor AEV E-Viecle thumbnail-1
Power Electronic Capacitor AEV E-Viecle photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Kowary
Place of Origin:
China
Model Number:
3x80uF 850VAC
Contact Supplier Request Quote Chat Now
Kowary Technology Co., Limited
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Kowary
Place of Origin China
Model Number 3x80uF 850VAC
Type Polypropylene Film Capacitor
Application Power
Rated Voltage 400 to 1000 Vac
Operating Temperature - 40 to + 85 ℃
Package Type Through Hole
Capacitance 3 x 20 to 3 x 500 μF

■GENERAL TECHNICAL CHARACTERISTICS

Reference standards   IEC 61071

Dielectric              Polypropylene film

Construction   Dry construction, Non-inductive type

Case                 Aluminum case

Leads               Threaded insert M8 or M10, Lead screw M8

Dissipation factor                    ≤2.0×10-3 Measured at 100 Hz and 20±5℃

Self inductance                         ≤100nH

Life expectancy                      30,000 hours at UNDC and 70 ℃(Hot-spot temperature)

Dielectric strength                1.5×Urms applied to 10s at 20±5 ℃

Test voltage terminal to case     3KVAC/50Hz for 60s

Insulation resistance(IR*CN)      ≥ 5000s but need not exceed 30GΩ, after 1 minute of electrification at 100Vdc (20±5℃)


■ELECTRICAL SPECIFICATION                                                         Unit: mm

Remark: 1. *** Internal code.

      2. Customization for special specification and requirement is available.



Product Tags: Capacitor , power electronic , E-Viecle
