Model: TL20A for EU |
||
|
Description of the Production The TL20A wheel loader is an earth-rock construction mini machine widely used in road, railway, construction, hydropower, port, mining and other construction projects. It is mainly used for shovel loading bulk materials such as soil, sand, lime, coal, hard soil, etc. Different auxiliary work devices can be used for loading and unloading of bulldozers, lifting and other materials such as wood. In the construction of roads, especially in high-grade roads, loaders are used for the filling and excavation of sub-grade works, asphalt mixing materials and aggregate and loading of cement concrete yards. In addition, you can carry out operations such as pushing soil, leveling the ground, and pulling other machinery. Because the loader has the advantages of fast operation speed, high efficiency, good maneuverability and light operation, it has become one of the main types of earth and stone construction in engineering construction.
This product with beautiful appearance, high configuration, superior performance, low fuel consumption, wide operating range. Use the quick hitch can add the attachment tools like auger, hydraulic hammer, loading bucket, gripper and so on. It can reduce maintenance and operating costs. Liberate the workforce, improve the mechanization, low investment, high return. |
||
| Advantages of TL20A wheel loader | ||
|
Adopt CUMMINS, weichai Deutz or YUCHAI engine, powerful and reliable. Torque converter and counter-shaft trans mission gearbox, assembled separately, higher reliability and easier maintenance.
|
||
|
|
|
| Specifications of TL20A wheel loader |
||
| 1.0 Engine details: Model Engine typeyuchaiRated Power70kwRated Speed2400rpmRated loading weight2000kg2.0 Transmission System TypeFour-wheel full hydraulic driveTransmission gear box form2 gear hydraulic variable speed changesRated input speed2500 (rpm)3.0 Bucket Bucket Capacity1.00CBMBucket width2000mmBucket typeHeavy-duty bolt on teethMax. Breakout Force60KNRated Load2000kgOperating Weight5900kg4.0 Overall Dimensions Overall Length (Bucket on ground position)5800mmOverall Height2750mmGround to Cab Top2750mmDumping Height2800mmMin. Base to the Ground350mmOverall Width2000mm5.0 Operating Specifications Steering SystemArticulated Frame with hydraulic power steeringMin Turning Radius4600mmDriving SystemFour wheel drive6.0 Brake System Service BrakeFour-wheel hydraulic spread-shoed brakeParking BrakeHand operated 7.0 Tyre Model16/70-208.0 Wheelbase2350mm9.0 Track base1500mmMaximum speed25km/hLifting time≤5.0sReach fully raised1050mmThe minimum circle diameter310mm
|
||
|
Standard Equipment Optional Equipment |
||
|
Dongfanghong 4108 Engine. 4 Cylinder Engine. Automatic with Torque Converter. 4 Wheel Drive. Standard Bucket. Wheel reduction axle. 220V Engine Pre-heater. Cabin Heater. Air Pre-heater. Luxury Cabin. Adjustable Steering Wheel. Quick Hitch. Mechanical joystick. Lock For Lifting And Steering Cylinder. Easy-damaged Spare Parts. |
Yunei engine. LED Lights. Video For Backward. E-mark Seat. Tipping Cabin. 3 Way or 4 Way Hydraulic Joystick. Electric Joystick. E4 Lamp. Rear Hydraulic System. Varta Anti-free Battery. Floating Function. TITAN WHEEL LOADERS, YOUR BEST PARTNER! |
|
| ATTACHMENTS | ||
| Grab BucketScreening Bucket4 in 1 bucketRipperLog GrapplePallet Fork2 in 1 BucketRoad SweeperRoad SweeperHydraulic HammerSnow BladeAdjustable Pallet ForkAugerQuick HitchGrass ForkStick RakeAngle BladeHay Fork360 Log GrabGrass Blade | ||
