High Quality FT5 Transformer Oil Filtration Machine
US$ 100 - 300
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
LEFILTER
Place of Origin:
China
Model Number:
FT5
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
7 days
Related Products
-
Hydraulic Oil Filtration Machine FT5 for Power PlantUS$ 100 - 300MOQ: 1 Set -
Portable Oil Filtration Unit FT5 for Power PlantUS$ 100 - 300MOQ: 1 Set
-
Top Quality FT5 Transformer Oil Filtering MachineUS$ 100 - 300MOQ: 1 Set
-
Supply FT5 Hydraulic Oil Filtration CartUS$ 100 - 300MOQ: 1 Set
-
Supply FT5 Oil Filtration Unit for Power PlantUS$ 100 - 300MOQ: 1 Set
Brand Name
LEFILTER
Place of Origin
China
Model Number
FT5
After-sales Service Provided
Engineers available to service machinery overseas
Warranty
2 years
High quality FT5 transformer oil filtration machine
Description:
The barrel transportation and filtration trolley FT 5 is a mobile oil service unit. It fills/filters hydraulic and lubrication tanks. The unit is designed to carry a standard oil drum (200 l).There is also the option to bypass the filter when emptying tanks (Version F).
Applications:
Hydraulic and lubrication oil systems in a variety of industries
Advantages:
Convenient offline filtration
Easy, safe transport of a 200 l standard oil drum
Easy to operate
Filling to a defined cleanliness class
Greater system availability
Reduction in Life Cycle Cost LCC
Technical specifications:
| Max. flow rate | 30/40 L/min |
| Voltage | 230V 50Hz,380-420V 50Hz,440V-480V 60Hz |
| Micron | 3-40μm |
| Operating pressure | 4.5 bar max. |
| Viscosity range | 15 ... 800 mm²/s (version-dependent) |
| Permitted operating fluid | Mineral oil (others on request) |
| Permitted suction pressure at suction port | -0.4 bar to +0.6 bar |
| Fluid temperature | -10 ... 80 °C |
| Ambient temperature | -20 ... 40 °C |
| Seals | NBR |
| Protection class | IP 54 |
| Power cable length | 6 m |
| Hoses length | 3 m |
| Hose connections |
Suction hose NW 30 with lance Pressure hose NW 25 with lance |
| Weight | ≈ 160 kg |
| Accessories |
Pistol grip filling nozzle Flow meter |
| Sizes | 1500x820x860mm |
Mode Code:
Dimensions:
Replacement elements:
| Filter size | Filtration rating | Element type | Part No. |
| 1 | 3 µm | 0330 R 003 BN4HC/-KB (-V-KB) | 1262999 (1263640) |
| 1 | 5 µm | 0330 R 005 BN4HC/-KB (-V-KB) | 1263000 (1263641) |
| 1 | 10 µm | 0330 R 010 BN4HC/-KB (-V-KB) | 1263001 (1263642) |
| 1 | 20 µm | 0330 R 020 BN4HC/-KB (-V-KB) | 1263002 (1263643) |
| 1 | 40 µm | 0330 R 040 AM/-KB (-V-KB) | 1272067 (1266563) |
| 1 | 3 µm | 0330 R 003 BN/AM/-KB (-V-KB) | 1272069 (1276690) |
| 1 | 10 µm | 0330 R 010 BN/AM/-KB | 1272068 |
| 2 | 3 µm | 1300 R 003 BN4HC/-KB (-V-KB) | 1263059 (1263760) |
| 2 | 5 µm | 1300 R 005 BN4HC/-KB (-V-KB) | 1263060 (1263761) |
| 2 | 10 µm | 1300 R 010 BN4HC/-KB (-V-KB) | 1263061 (1263762) |
| 2 | 20 µm | 1300 R 020 BN4HC/-KB (-V-KB) | 1263062 (1263763) |
| 2 | 40 µm | 1300 R 040 AM/-KB | 1267699 |
| 2 | 3 µm | 1300 R 003 BN/AM/-KB | 1267991 |
| 2 | 10 µm | 1300 R 010 BN/AM/-KB (-V-KB) | 1270010 (1276060) |
