Help CenterMarine Centrifugal Mushroom Ventilator
Product Spotlights
Related Products
-
Marine Equipment Steel Manhole Cover Manway CoverNegotiableMOQ: 1 Piece -
Marine Manhole Cover Manway Cover Marine Steel Manhole CoversNegotiableMOQ: 1 Piece
-
Cast Steel Marine Roller Lever Chain Stopper Marine Mooring EquipmentNegotiableMOQ: 1 Piece
-
Marine Mooring Disc Type Quick Release Towing Mooring HookNegotiableMOQ: 1 Kilogram
-
Marine Quick Release Hook Single Hook Double HookNegotiableMOQ: 1 Kilogram
1 WORKING CONDITIONS
Medium temperature: -25~ +50 centigrade
Max relative humidity: 95%
Periodical swing: ±22.5°
Continued transversal incline: ±15°
Continued longitudinal incline: ±10°
Vibration: existent
Impact: existent
2 CHARACTERISTICS
Small size and light weight.
Low noise and low vibration.
Good anti-corrosiveness.
Good air tightness.
Small starting torque.
Strong resistance against swing,
vibration and impact.
3 PERFOMANCE SELEDTION
The performance parameters shown in the tables are the air properties under standard atmospheric conditions ( i. e. the atmospheric pressure 101325 Pa; temperature 20 centigrade; relative humidity 50% and the air specific gravity 1.2
In case the actual air conditions and the rotating speed differ from those shown in the tables, the performance of the ventilator can be
converted according to the following formulas:
Q=Q0· ( m3/h )
P=P0·( )2· ( Pa )
N=N0·( )3· ( KW )
Among which
Q0 ,P0 ,N0, are the volume of flow, pressure, power, and the specific gravity under standard air conditions and rotating speed.
Q,P,N,ρ,n indicate the actual volume of flow, pressure, power and air specific gravity and rotating speed.
Remarks:
1.The allowable error of the full pressure value under standard volume is -5%~+10%.
2. The limit values of noise of the ventilator is
LA≤26+10 lgP2Q
where P-mmH2O
Q-m3/min
The ventilator can be matched with marine AC motor of 380V, 50HZ or 440V, 60HZ types.
