LEO 6000S-40 Quality Assurance 6 Mega Rolling Shutter USB3 Vision USB Camera Module
US$ 490 - 576
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Contrastech
Place of Origin:
China
Model Number:
LEO 6000S-40um/uc
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LEO 5470S-14 High Quality 20 Mega Rolling CMOS Machine Vision Compact Camera for Color SorterUS$ 810 - 960MOQ: 1 Piece -
LEO 9MS-30 China Supplier High Resolution 12mp Global Shutter 1 Inch Camera USBUS$ 1550 - 1860MOQ: 1 Piece
-
LEO 12MS-23 Professional SDK High Performance 12MP IMX304 Global Shutter Barcode Reader CameraUS$ 1950 - 2100MOQ: 1 Piece
-
LEO 12MX-30 CE Certificate XGX12000 Mono 12 Megapixels External Trigger CameraNegotiableMOQ: 1 Piece
-
LEO 1440S-166 Wholesale 1.5 Mega IMX273 Global Shutter USB3.0 Vision Camera System for Quality ControlUS$ 375 - 438MOQ: 1 Piece
Brand Name
Contrastech
Place of Origin
China
Model Number
LEO 6000S-40um/uc
Type
Digital Camera
Special Features
Other, usb camera module
Technology
NetWork
Sensor
CMOS
Style
Other, Machine Vision Camera
MAIN FEATURES
■ Wide range of resolution
Resolution from VGA to 20MP for various applications.
■ High quality sensors
Lastest Python series sensor from On-Semiconductor and SONY Pregius CMOS sensors provide high quality images.
■ Frame Rate up to 815 fps
High frame rate ideal for high speed applications.
■ 128 MB RAM
Internal memory up to 128 MB guarantees no image loss.
■ One-cable solutions
Gigabit Ethernet with PoE, USB 3.0
■ Outstanding price/performance ratio
| Model | LEO 5000P-30uc | LEO 6000S-40um/uc | LEO5000S-35um/uc | LEO5000A-30um/uc | LEO 5000P-60um |
| Resolution (H*V pixels) | 2592 × 2048 | 3072 × 2048 | 2448 x 2048 | 2592 × 2048 | 2592 × 2048 |
| Sensor | ON Semiconductor PYTHON 5000 | SONY IMX178 | SONY IMX264 | ON Semiconductor AR0521 | ON Semiconductor PYTHON 5000 |
| Sensor Size (optical) | 1'' | 1/1.8'' | 2/3'' | 1/2.5'' | 1'' |
| Sensor Technology | CMOS, Global | CMOS, Rolling |
CMOS, Global |
CMOS, Rolling | CMOS, Global |
| Pixel Size (μm2) | 4.8 × 4.8 | 2.4 × 2.4 | 3.45 × 3.45 | 2.2 x 2.2 | 4.8 x 4.8 |
| Frame Rate (fps) | 30 | 43 | 35 | 30 | 60 |
| Data Bits | 8bit / 10bit / 12bit | ||||
| Exposure Time | 50μs~10s |
um-16μs~1s uc-24μs~1s |
50μs~10s | 16μs~1s | 50μs~10s |
| Dynamic Range | >60dB | >65dB | >60dB | >60dB | >60dB |
| Mono/Color | Color | Mono/Color | Mono/Color | Mono/Color | Mono |
| Image Format | Mono: Mono8/10/10p/12/12p Color: Bayer RG 8/10/10p/12/12p |
||||
| Interface | USB3.0 | ||||
| Synchronization | Via hardware trigger, via software trigger or free run. | ||||
| Programmable Control (ISP) | Image Resolution, RGB gain, Exposure Time, Contrast, Gamma Chart, Image Rollover, Raw, LUT, Black Level Correction | ||||
| Housing Size (L*W*H) | 29.0 mm × 29.0 mm × 30.0 mm (55g) (*B) | ||||
| Operating Temperature | -30~80 °C (Storage), 0~50°C (Working) | ||||
| Lens Mount | C-Mount | ||||
| Digital I/O | 1 opto-isolated input, 1 opto-isolated output, 1 bidirectional custom non-isolation I/O | ||||
| Power Input | DC 5-15V, Supporting USB Power Supply | DC 5-15V, Supporting USB Power Supply | DC 5-15V, Supporting USB Power Supply | DC 5-15V, Supporting USB Power Supply | DC 5-15V, Supporting USB Power Supply |
| Power Consumption | 12V@2.7W | 12V@2.6W | 12V@2.5W | 12V@2.5W | 12V @2.7W |
| Driver | LEO Series Camera Software Suite or 3rd party GigE Vision Software | ||||
| Operating System | Windows, Linux,Arm | ||||
| Conformity | GigE Vision, GenICam | ||||
APPLICATIONS
1. Defect inspection;
2. SMT;
3. Vision localization;
4. Dimension measurement;
5. Barcode reading;
6. VR/AR;
7. Logistic Industry
You can refer to the Brochure by click below links of dropbox:
/s/i0axwmrpuj6eam5/Porduct%20Brochure%20-%20CONTRASTECH.pdf?dl=0
