US$ 16350 - 17700 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Huaxiamaster
Place of Origin:
China
Type:
Core Drilling Rig
Contact Supplier Request Quote Chat Now
Shandong Master Machinery Group Co.,Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
5 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Huaxiamaster
Place of Origin China
Type Core Drilling Rig
Certification ISO9001
After-sales Service Provided Engineers available to service machinery overseas
Warranty 6 months
Weight 500kg
Power Type Electric
Usage Ore
Condition New
Power(W) 30kw

KY-250 hydraulic exploration drilling rig for metal mine

1. Brief introductions of KY-250 hydraulic exploration drilling rig for metal mine

The KY250 hydraulic exploration drilling rig for metal mine is

· small in size

· light weight

· convenient to install and operate

· excellent linkage and adjustable speed range

· suitable for drilling at any angle in the tunnel or surface.

2. Specifications of KY-250 hydraulic exploration drilling rig for metal mine

Drilling diameter

Φ36.5mm /Φ46.5mm

Drilling depth

250m（ø33 Steel drill pipe）/200m（ø43 Steel drill pipe）

Borehole angle

0°-360°

Spindle speed

400-1400r/min

Spindle output torque

150-400nm

Rated pulling force

40kn

Rated pulling speed

＞0.3m/s

Oil supply mode

double gear pump

Rated system pressure

16mpa

Oil pump model

CBF-F71/10

Hydraulic oil model

antiwear hydraulic oil YB-N46/YB-N32 (winter)

Motor model

manual variable motor A6V80MA

Motor specification

30kw

Weight

main engine 275kg/backbone 40kg/operating floor86kg/power car 420kg
