OCC Paper Hydrapulper for Paper Mill
- 10 Set / Sets per Month
- Qingdao Port
- T/T
You May Like
Product Details
| Warranty | One Year |
Product Description
FGS vertical high consistency hydrapulper machine, under high consistency and high temperature conditions (10%-15%, 70-90℃), makes the paper withstand a strong eddy current circulation, and produce strong friction, tear and rub, so that the paper material is completely dissolved. Not only the fiber length and strength are ensured, but the impurities in the waste paper are crushed, and the ink pigment is more easily separated from the fiber, and the removal effect of the hot-melt is more obvious, thus the fine pulping effect is achieved.
Model | Nominal capacity(m³) | Capacity(T/D) | Pulp consistency(%) | Power supply(KW) |
FGS-1 | 1 | 3-6 | 15±2 | 22 |
FGS-2 | 2 | 5-8 | 15±2 | 37 |
FGS-3 | 3 | 9-12 | 15±2 | 55 |
FGS-5 | 5 | 13-18 | 15±2 | 75 |
FGS-8 | 8 | 20-30 | 15±2 | 110 |
FGS-10 | 10 | 30-45 | 15±2 | 160 |
FGS-15 | 15 | 45-60 | 15±2 | 220 |
FGS-20 | 20 | 60-90 | 15±2 | 315 |
FGS-25 | 25 | 90-120 | 15±2 | 450 |
FGS-30 | 30 | 120-150 | 15±2 | 500 |
FGS-35 | 35 | 150-180 | 15±2 | 560 |
FGS-40 | 40 | 180-220 | 15±2 | 630 |
FGS-45 | 45 | 200-270 | 15±2 | 710 |
FGS-50 | 50 | 220-300 | 15±2 | 800 |
Our Services
Fangyuan Zhonghe has a complete sales service system, which is composed of marketing, distribution management, direct sales business, technical support, after-sales service, regional development and other parts of the network throughout the country. These network nodes form an organic whole with the company headquarters and serve the users wholeheartedly.
Shandong Fangyuan Zhonghe Machinery Co., Ltd. (formerly Zhucheng Fangyuan Machinery Co., Ltd.) is the backbone enterprise specializing in the production of environmental-friendly pulp and papermaking equipment, tissue paper machine and sewage treatment equipment. The company is next to Qingdao free trade zone Zhucheng functional area. The main products include two categories, more than 50 series, sewage treatment equipment, pulp and papermaking equipment and crescent tissue paper machine. With the high technology content, it has reached the advanced level of the same industry in China.
A: Yes, we have been concentrating on this series of products for more than 20 years of experience
A: We can give you guide by video, voice, email by all kinds of chatting APP
If there's still doubt, we can arrange the professional engineer to install in your country.
A: We have FGS-1, FGS-2,FGS-3, etc.
You can choose the model you need according to your parameters.
A: Normally as the export standard or as your needs
A: Qingdao port, etc.
Q6. Do you offer guarantee for the products?
A: Yes, under the right condition, we can offer time warranty for our products
