CNC Bending Machine
Hydraulic Bending Machine Parameters
1) Max bending thickness: 4mm
2) Length of working table: 3200m
3) Nominal pressure: 1000KN
4) Strength of bending material: 450N/m㎡
5) Ram stroke: 150mm
6) Max open height between table bench and slide block: 405mm
7) Depth of throat: 320mm
8) Speed of slide block: free 50mm/s, work 7mm/s, Return stroke 60mm/s
9) Length of blade: 3300mm
10) Material of blade: China material 9CrSi
11) Height of working table: 700mm
12) Main motor: 7.5kw, 1440rpm
13) Back gauge motor: 0.75kw, 910rpm
14) Pump: 16L/min, 32MPa
15) Max working pressure of hydraulic system: 25MPa
16) Main electrical parts supply by schnider
17) Power supply: 380V, 3 Phase, 50Hz(or as per your request)
18) Machine size: about 3650mmx1650mmx2300mm
SALES TERMS
1). Machine Price: Please contact us, we will try to give you good discount for starting our cooperation
2). Payment term: 30%TT should be paid as advance deposit, 70%TT before shipment
Or 100% LC at sight
3). Package: naked with simple plastic film and loaded in one 20-feet container
4). Delivery time: 50 working days after receipt of the deposit
5). Guarantee: 12 months. If any part of machine breaks, we will supply it for free.
6). After sales service
This producing line is maintained free of charge for 12 months. When the machine is used in China, we will install and debug the machine for free; if it is used at abroad, we will send the professional technician to debug. Buyers should take all the fees for technicians traveling abroad, and pay 100USDdayperson. We are Hydraulic Bending Machine Factory
