A5 Automatic Solder Paste Printing Machine

Name: A5 Automatic Solder Paste Printing Machine
Brand: Fully Automatic Vision Printer
SKU: 161296861
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

Fully Automatic Vision Printer

Place of Origin:

Afghanistan

Model Number:

Shenzhen Right Automation Equipment Co., Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Brand Name Fully Automatic Vision Printer

Place of Origin Afghanistan

Model Number A5

After-sales Service Provided Engineers available to service machinery overseas

Weight Approx:1000kg

Usage Other, --

Condition New

Automatic Grade Other, --

Dimensions(L*W*H) 1220（L）×1355（W）×1500（H）mm

Color & Page Other, --

Plate Type Other, --

Detailed Product

one. Machine specification parameters

Model			A5
Item
Screen Frames		Min Size	470×370mm
		Max Size	737×737mm
		Thickness	25~40mm
PCB Min Size			50×50mm
PCB Max Size			400×340mm
PCB Thickness			0.4~6mm
PCB Warpage
Transport Height			900±40mm
Transport Direction			Left-Right;Right-Left;Left-Left;Right-Right
Transport Speed			Max 1500mm/s（Programmable）
Board Location PCB The positioning	Support System		Magnetic Pin/Up-down table adjusted/support block
	Clamping System		Side clamping,vacuum nozzle
Printer Head			Two independent motorised printhead
Squeegee Speed			6~200mm/sec
Squeegee Pressure			0~15kg
Squeegee Angel			60°/55°/45°
Squeegee Type			Stainless steel（standard）,plastic
Stencil Separation Speed			0.1~20mm/sec （Programmable）
Cleaning System			Dry 、Wet、Vacuum （Programmable）
Table Adjustment Ranges			X:±10mm;Y:±10mm;θ:±2°
Machine
Repeate Position Accuracy			±0.01mm
Printing Accuracy			±0.025mm
Cycle Time			（Exclude Printing & Cleaning）
Product Changeover
Air Required			4.5~6kg/cm²
Power Input			AC:220±10%,50/60HZ1F3KW
Control Method			PC Control
Machine Dimensions			1220（L）×1355（W）×1500（H）mm
Machine Weight			Approx:1000kg
