Assemble wedge key driver machine for forging Hammer

Introduction of DXT series Pin assemble machine for forging hammer change mold

Pin assemble machine is one of our main products which are widely applied in forging industry, suitable for quick-change the forging mold from the forging equipment, like forging hammer or forging press. Instead of using the heavy steel block with the crane, DXT series Pin assemble machine is more high-efficiency and safer than the traditional way.

On the other hand, using the Pin assemble machine will save time and save labor costs. Usually, one work can finish the forging mold quick-change work by pin assemble machine.

The parameter of Pin assemble machine for forging hammer change mold:

Machine type: DXT-100

Max impact energy: 1 KJ

Pressurised air connection: 1 Inch

Max wedge dimension: 60*80*500 mm

Working pressure: 0.6-0.8 MPa

Max piston stroke: 400 mm

Weight: 860 kg

Matched forging hammer hit energy: 0-25 KJ

Introduction of Anyang Forging Press Machinery Industry Co., Ltd

Anyang Forging Press (Group) Machinery Industry Co., Ltd is the biggest forging equipment manufacturer in China, Our company has 60 years history in Producing forging machine. Our company has been identified as the national high-tech company. Our company is one of the high-tech and high-growth enterprise in Henan Province. We are the executive director of China Forging Association and the Vice President of Henan Forging Association.

Our company has passed ISO9001: 2008 quality certificate and our hammer have passed CE certification. Two products have been given the original certificate to protect the best quality machines.

Our company covers about 60 acres with four branch factories. Our company has the provincial level products designed research center and has sales center, after-sales center, quality control and management center, machining center and large heat treatment and product assembly center, which can provide the compete set of forging equipment.

Our products have been exported to USA, Germany, Japan, Korea, Russia, UK, France, Australia, India, Vietnam, Pakistan etc 60 countries and gain high reputation all over the world.

Q: How long is your delivery time?

A: Generally it is 30-60 days, if the goods are in stock,  it will be 20-35 days. If the goods are not in stock, it is according to quantity.

Q: Are you trading company or manufacturer?

A: We are factory.

Q: What are your terms of payment?

A: Payment

If you have another question, pls feel free to contact us as below:
