High Strength Tecco Mesh For Rockfall Protection / Steel Tecco Wire Mesh

High Strength Tecco Slope Stabilization System / Slope Stabilization Protective Mesh

Product description:

Rockfall protection system Also known as tecco system, consists of five main components, as below:

1). Rockfall protection netting(Tecco mesh)

Rockfall protection mesh is made of high-tensile steel wire with an ultimate tensile strength of 1770 N/mm2.

2). Claw type Spike Plate

The claw type spike plate is commonly used with nails to fasten the tecco mesh onto the slope firmly. The claw design make the spike plate a more stable and firm structure.

The plates are galvanized and have dimensions of 13.0”*7.5″*0.4″(330mm*190mm*10mm), also can be customized.

3). Tecco mesh connection fittings

There are 2 types of connection way for Tecco mesh, Clips or Sewing rope.

Connection Clips. The connection clips are used to connect the neighbor tecco mesh rolls firmly, and the connection is commonly without overlap, these claw are hot dip galvanized and consist of 0.25″(6mm) thick steel spiral.

Sewing rope, it’s used for connecting the neighbor tecco meshes. And the connection is commonly have overlaps. It can be used to replace the clips.

4). Soil or rock nails

The main anchors of the system are installed in a grid typically from 6.6 to 13.1 ft (2.0 to 4.0m) horizontal and vertical spacing, Anchor consist of steel bars ranging from 1.0 to 1.25 ft (25 to 32mm).

5). Boundary rope.

Pass through the tecco mesh and then be fixed onto the anchor for tecco mesh and system stability.

Tecco mesh Advantages:

Safety.
The tecco mesh can be used to stabilize any kinds of slope, including rocks and loose soil slopes.

High tensile strength.
The tecco mesh is made of high tensile steel wire, which the tensile strength is more than 1770 MPa, which can supply maximum protection to the slope and people.

Environmental friendly.
The rhomboid mesh can let the plants grow regularly and make the slope or maintain be more beautiful.

Rhomboid mesh structure.
This structure provide most stability for the geological conditions and can be tightly secured on the slope even on the irregular mountains.

Knotted ends.
Different from the chain link fence which has wrapped edge, the tecco mesh has knotted ends which can improve the tensile strength and stability of the structure.

Lightweight.
The tecco mesh has excellent strength-to-weight ratio, which make it easy to install and transport.

Durable.
Heavy zinc coated surface let the tecco mesh has outstanding corrosive resistance performance, and the high tensile strength material make the tecco mesh be used for a long service life.

Tecco mesh Applications:

The whole system is composed of high-strength steel wire, bolt and other installation components, also known as safety netting system, it’s widely used to cover and intercept slope reinforcement, to defend various geological disasters. It can not only stabilize the slope and replace the traditional mortar slag stones structure, it is also environmental friendly, which can ensure the plant growth.
