Best Selling Transformer Oil Breakdown Voltage Dielectric Strength BDV Analyzer Insulating Oil Tester

Why buy from us?

1. We are one of the largest manufacturers & exporters of oil purifier inChina

2. We have more than 10 years export experience

3. We offer our customers high quality products at competitive price

4. We offer our customers excellent after-sales service

5. We are not satisfied until our customers are satisfied!

UNIQUE FEATURES:

1. JS-023A provides all the mainstream testing standard, such as IEC-60156, IS6792, BS5874, ASTM D-877, ASTM D-1816, no matter where you are, there always has a suitable standard for you.

2. 7 inches colorful LCD touch screen.

3. All the selection can be finished on touch screen.

4. Oil temperature measurement.

5. RS232 interface.

TECHNICAL INDEX:

1. Voltage OEM for clients

2. AC220V±10% power supply input, or OEM for clients

3. Output voltage: 0 – 100KV

4. Rate of voltage rise: 0.5kv/s±10%, 2kv/s±5%, 3kv/s±5%, 5kv/s±5%

5. Max test times: 9

6. Init wait times: 0 - 999s

7. Stir time: 0 - 999s

8. Wait time: 0 - 999s

9. Measurement accuracy: ± (1% of full scale + 2 digits) Resolution: 0.1KV

10. Temperature measurement:

11. Measurement range: 0°C to 70°C, or better

12. Temperature resolution: 1°C, or better

13. Operating temperature: up to 45°C

14. Storage: 100 groups

15. 7 inch colorful LCD with touch pad

16. Oil test vessel temperature measurement unit

17. All the selection can be done by touch panel with color LCD screen.
