450V fan sh CBB61 capacitor

Name: 450V fan sh CBB61 capacitor
Brand: Mascotop
Price: USD $0.28 - 0.91 / Piece

FOB Price

USD $0.28 - $0.91 / Piece

1 Piece(Min.Order)

Supply Ability 1000000 Piece / Pieces per Month
Port shanghai
Payment Terms:T/T
Delivery Detail:7 days

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	Mascotop	Place of Origin:	China	Model Number:	CBB61
Type:	Polypropylene Film Capacitor	Application:	Air Conditioner	Rated Voltage:	150~500V.AC
Operating Temperature:	-40~85℃	Package Type:	Other	Capacitance:	0.5~30uF (uF=MFD)

Product Description

Product Structure

Shell Material: ABS, PP

Capacitor Lead Ways: Terminal tabs

Features And Uses

The capacitor has advantages of low dissipation, high insulation resistance, good self-healing character, and steady electricity performance, anti-striking current, strong over-carrying capacity etc, in generally, it uses rectangular flame retardant shell and epoxy resin to seal. Suitable for electric fan, exhaust fan, water pump, and Electric sewing machine etc products. Contribute to motor’s starting and running.

Technical Parameter

Rated Voltage: 150~500V.AC

Nominal Capacitance: 0.5~30μF (μF=MFD)

Capacitance Tolerance: ±5%

Operating Frequency: 50Hz/60Hz

Climate: 40/85/21

Ambient Temp: -40~85℃

Test Voltage: T-T: 2Un/2S, T-C: 2200V.AC/2S

Dissipation Factor (loss): tan δ≤0.002 (100Hz)

Class of Safety protection: S0, S1, S2, S3

Class of operation: CLASS A(30000H), CLASS B(10000H), CLASS C(3000H)

Executing Standards: IEC60252，EN60252，VDE0560-8, UL810, GB/T3667.1-2005

Valid certification: ISO9001, ISO14001, CQC, UL, CE, TUV, VDE, CSA, ROHS

No.	Specification	Shell size
01	CBB65, 450V.AC, 20uF, ±5%, 2+4 250#	Φ45*75mm
02	CBB65, 450V.AC, 25uF, ±5%, 2+4 250#	Φ45*100mm
03	CBB65, 450V.AC, 30uF, ±5%, 2+4 250#	Φ45*100mm
04	CBB65, 450V.AC, 35uF, ±5%, 2+4 250#	Φ50*100mm
05	CBB65, 450V.AC, 40uF, ±5%, 2+4 250#	Φ50*100mm
06	CBB65, 450V.AC, 45uF, ±5%, 2+4 250#	Φ50*110mm
07	CBB65, 450V.AC, 50uF, ±5%, 2+4 250#	Φ50*110mm
08	CBB65, 450V.AC, 60uF, ±5%, 2+4 250#	Φ50*125mm
09	CBB61, 450V.AC, 1uF, ±5%, 2+2 187#	122637
10	CBB61, 450V.AC, 1.2uF, ±5%, 2+2 187#	122637
11	CBB61, 450V.AC, 1.5uF, ±5%, 2+2 187#	152637
12	CBB61, 450V.AC, 2uF, ±5%, 2+2 187#	152637
13	CBB61, 450V.AC, 2.5uF, ±5%, 2+2 187#	182837
14	CBB61, 450V.AC, 3uF, ±5%, 2+2 187#	182837
15	CBB61, 450V.AC, 3.5uF, ±5%, 2+2 187#	182947
16	CBB61, 450V.AC, 4uF, ±5%, 2+2 187#	182947
17	CBB61, 450V.AC, 4.5uF, ±5%, 2+2 187#	183447
18	CBB61, 450V.AC, 5uF, ±5%, 2+2 187#	183447
19	CBB61, 450V.AC, 6uF, ±5%, 2+2 187#	223447
20	CBB61, 450V.AC, 7uF, ±5%, 2+2 187#	223447
