Single Strand Wire Ropes

Negotiable MOQ: 5 Tons (Price negotiable depending on order volume and customization)

Key Specifications

Business Type:

Manufacturer

Year Established:

2012

Product Certifications:

ISO9001

Nantong Coredom Wire&Rope Company Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

nantong,shanghai port

Delivery Detail:

Delivery time depends on order quantity.

丝绳公称直径Norminal Diamater/mm	参考重量Approximate Weight/(kg/100m	钢丝绳公称抗拉强度Norminal Tensile Strength/Mpa
		1570	1670		1770		1870
		钢丝绳最小破断拉力MBL/KN
0.6	0.19	0.31		0.32		0.34		0.36
1.2	0.75	1.22		1.3		1.38		1.45
1.5	1.17	1.91		2.03		2.15		2.27
1.8	1.69	2.75		2.92		3.1		3.27
2.1	2.3	3.74		3.98		4.22		4.45
2.4	3.01	4.88		5.19		5.51		5.82
2.7	3.8	6.18		6.57		6.97		7.36
3	4.7	7.63		8.12		8.6		9.09
3.3	5.68	9.23		9.82		10.4		11
3.6	6.77	11		11.7		12.4		13.1
3.9	7.94	12.9		13.7		14.5		15.4
4.2	9.21	15		15.9		16.9		17.8
4.5	10.6	17.2		18.3		19.4		20.4
4.8	12	19.5		20.8		22		23.3
5.1	13.6	22.1		23.5		24.9		26.3
5.4	15.2	24.7		26.3		27.9		29.4
6	18.8	30.5		32.5		34.4		36.4
6.6	22.7	36.9		39.3		41.6		44
7.2	27.1	43.9		46.7		49.5		52.3
7.8	31.8	51.6		54.9		58.2		61.4
8.4	36.8	59.8		63.6		67.4		71.3
9	42.3	68.7		73		77.4		81.8
9.6	48.1	78.1		83.1		88.1		93.1
10.5	57.6	93.5		99.4		105		111
11.5	69	112		119		126		134
12	75.2	122		130		138		145

钢丝绳公称直径Norminal Diamater/mm	参考重量Approximate Weight/ (kg/100m)	钢丝绳公称抗拉强度Norminal Tensile Strength/Mpa
		1570	1670	1770	1870
		钢丝绳最小破断拉力MBL/KN
1	0.51	0.83	0.89	0.94	0.99
1.5	1.14	1.87	1.99	2.11	2.23
2	2.03	3.33	3.54	3.75	3.96
2.5	3.17	5.2	5.53	5.86	6.19
3	4.56	7.49	7.97	8.44	8.92
3.5	6.21	10.2	10.8	11.5	12.1
4	8.11	13.3	14.2	15	15.9
4.5	10.3	16.9	17.9	19	20.1
5	12.7	20.8	22.1	23.5	24.8
5.5	15.3	25.2	26.8	28.4	30
6	18.3	30	31.9	33.8	35.7
6.5	21.4	35.2	37.4	39.6	41.9
7	24.8	40.8	43.4	46	48.6
7.5	28.5	46.8	49.8	52.8	55.7
8	32.4	56.6	56.6	60	63.4
8.5	36.6	60.1	63.9	67.8	71.6
9	41.1	67.4	71.7	76	80.3
10	50.7	83.2	88.6	93.8	99.1
11	61.3	101	107	114	120
12	73	120	127	135	143
13	85.7	141	150	158	167
14	99.4	163	173	184	194
15	114	187	199	211	223
16	130	213	227	240	254
