9 Gauge Aluminum Coated Steel Chain Link Fence Privacy Fabric Used in Commercial residential
Aluminum chain link fence is produced by cold-drawing good commercial grade steel rod into wire of the appropriate diameter. The steel rod from which the wire is drawn shall be produced by the open hearth, electric furnace or basic oxygen process. The coating is produced by passing the cleaned wire through a molten bath of aluminum metal.
Aluminum Chain Link Fencing Features: Corrosion resistance, Lightness and nice appearance, Long life time, High tensile and easy installation, Adapt to the harsh environment.
The base metal of the chain link mesh is composed of commercial quality medium-carbon aluminum coated wire. The wire is coated with aluminum to produce a smooth and uniform coating. The weight of aluminum coating, wire sizes with allowable variances, and wire breaking strength, conform to ASTM A 817 for the wire size specified. The wire is aluminum coated before weaving.
Standards:
ASTM A 491 Aluminum-Coated Steel Chain Link Fence.
ASTM F567 Installation of Chain Mesh Fencing.
ASTM A 817 Metallic-Coated Wire for use in Chain-Link Fence Federal specification. RR-F- 191 K/1 D Type II, Fencing, Wire and Post Metal (Chain-Link Fence Fabric) American Association of State Highway Transportation Officials M-181 Chain Link Mesh, Type II.
Specifications:
Aluminized fabric is available in mesh sizes from 3/8 inch to 2 inches, and in heights from 36 inches to 240 inches. Unless otherwise specified, chain link fabric woven with a 2 inch (50 mm) mesh and 60 inches (1,520 mm) or less in height is knuckled at both selvages;
Chain link fence end types: K- Knuckle, B- Barb.
| (Mesh × Gauge × Height) | Ends |
|---|---|
| 2" × 9 × 36" | K×K |
| 2" × 9 × 42" | K×K |
| 2" × 9 × 48" | K×K |
| 2" × 9 × 60" | K×K |
| 2" × 9 × 72" | K×B |
| 2" × 9 × 84" | K×B |
| 2" × 9 × 96" | K×B |
| 2" × 9 × 120" | K×B |
| 2" × 9 × 144" | K×B |
| Nominal Wire Diameter | Allowable Variance | Aluminum Coating Weight, minimum |
Breaking Strength minimum | |||||
| Gage | inch | inch | oz/ft2 | g/m2 | lbf | Newtons | ||
| 6 | 0.192 | 4.88 | +0.005 | +0.13 | 0.40 | 122 | 2,170 | 9,650 |
| 9 | 0.148 | 3.76 | + 0.005 | +0.13 | 0.40 | 122 | 1,290 | 5,740 |
| 10 | 0.135 | 3.43 | + 0.005 | +0.13 | 0.40 | 122 | 1,290 | 5,740 |
| 11 | 0.120 | 3.05 | + 0.005 | +0.13 | 0.35 | 107 | 850 | 3,780 |
|
|
| Aluminum Coated Steel chain link fence used as sport fence | Aluminum coated chain-link fence packed with yellow plastic bag |
Aluminum Chain Link Fencing Applications:
Aluminum coated (aluminized) steel chain link for commercial, industrial and institutional applications. Aluminized fabric is contained in various government specifications for use in prison, road, dock, airport, housing, forestry, and military use.
Aluminum chain link fencing using with barbed wire
Here is the chain link fence, barbed wire, other accessories specification needed.Standard 50 × 10 gauge (mesh × gauge) Aluminum chain link Mesh (3 m high × 2600 m length) (3.1 - 3.24 mm diameter).Strands of Aluminum Barded Wire (2.2 mm diameter). Strands of 3.25 mm straining wire (4.0 - 5.5 mm diameter). 25 × 4 mm galvanized steel metal beading.65 mm × 65 mm × 6 mm galvanized steel angle.Straight barbed wire: 2.5 mm diameter.Barbed wire spring (for making wire barbs): 2.2 mm diameter.Line straining wire (straight wire): 4.0 - 5.5 mm diameter.Chain link for mesh: 3.1 - 3.24 mm diameter.aluminum alloy is Al Mg 2.5 or equivalent.
| Materials | Straight barbed wire | Barbed wire spring | Line wire | Chain wire |
|---|---|---|---|---|
| Nominal diameter | 2.5 | 2.2 | 4.0 to 5.5 | 3.1 |
| Measured mean diameter | 2.5 | 2.20 | 3.98 | 3.09 |
| Sectional area | 4.91 | 3.8 | 12.44 | 7.5 |
| 0.2% proof load | 56 | 115 | 376 | 197 |
| 0.2% proof stress | 11.4 | 30.3 | 30.2 | 26.3 |
| Maximum load | 106 | 127 | 440 | 236.5 |
| Tensile strength | 21.6 | 33.4 | 35.4 | 31.5 |
| Elongation on gauge length 50 | 8 | 6 | 13 | 8 |
|
|
Aluminum coated chain link fence used for grass fencing |
Chain link fence provides security for the factory |
All our Aluminum coated steel chain link fence are backed by a 10 year warranty from the manufacturer.
Aluminum coated chain link fence
chain link fence for rural fencing
aluminum coated metal chain link fence for farm
aluminum coated metal chain link fence for details
