Automatic Lpg Gas Cylinder Filler Making Machine

FOB Price

USD $22 - $24 / Piece

1062 Pieces(Min.Order)

Supply Ability 100000 Piece / Pieces per Month
Port SHENZHEN SHANGHAI NINGBO
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	as per buyer's requirements	Model Number:	15kg lpg gas cylinder	Material:	Steel
Use:	LPG	Pressure:	Low

Product Description

3kg/7.2L refilled LPG cylinder
Brief introduction

Production standard: ISO4706; ISO22991; GB5842-2006
Material: cylinder body-SG295 (HP295)
Handle and base-Q235
Thickness of wall: 2.0mm
Water capacity: 7.2L
Net weight: 4.3kgs
Test pressure: 34 Bar
Work pressure: 18 Bar
Cylinder color can be changed as your request.
Gas valve can be changed other styles to suit for different area.

The cylinder can fix burner directly for household or camping cooking.

Specifications:

MODEL LPG-3KG(C)
Water Capacity	High total	Bottle		Base		Angle Valve
		Diameter	High	Diameter	High	W21.8/19.8
7.2L	310mm	206mm	240mm	205mm	42mm

5KG/12L refilled LPG cylinder
Brief introduction

Production standard: ISO4706; ISO22991; GB5842-2006

Material: cylinder body-SG295 (HP295)

Handle and base-Q235

Thickness of wall: 2.3mm

Water capacity: 12L

Net weight: 5.3kgs

Test pressure: 34 Bar

Work pressure: 18 Bar

Cylinder color can be changed as your request.

Gas valve can be changed other styles to suit for different area.

The cylinder can fix burner directly for household or camping cooking.

Specifications:

MODEL LPG-5KG(C)
Water Capacity	High total	Bottle		Base		Angle Valve
		Diameter	High	Diameter	High	M14*1.5
12L	390mm	226mm	355mm	205mm	42mm

6KG/14.4L refilled LPG cylinder
Brief introduction

Production standard: ISO4706; ISO22991; EN1442

Material: cylinder body-SG295 (HP295)

Handle and base-Q235

Thickness of wall: 2.3mm

Water capacity: 14.4L

Net weight: 7.8kgs

Test pressure: 34 Bar

Work pressure: 18 Bar

Cylinder color can be changed as your request.

Gas valve can be changed other styles to suit for different area.

The cylinder can fix burner directly for household or camping cooking.

Specifications:

MODEL LPG-6KG(C)
Water Capacity	High total	Bottle		Base		Angle Valve
		Diameter	High	Diameter	High	M16*1.5
14.4L	310mm	294mm	255mm	270mm	60mm

9KG/21.6L refilled LPG cylinder

Production standard: ISO4706; ISO22991; GB5842-2006
Material: cylinder body-SG295 (HP295)
Handle and base-Q235
Thickness of wall: 2.75mm
Water capacity: 21.6L
Net weight: 10.5kgs
Test pressure: 34 Bar
Work pressure: 18 Bar
Cylinder color can be changed as your request.
Gas valve can be changed other styles to suit for different area.

The cylinder can fix burner directly for household or camping cooking.

Specifications:

MODEL LPG-9KG(C)
Water Capacity	High total	Bottle		Base		Angle Valve
		Diameter	High	Diameter	High	As your request
21.6L	510mm	294mm	380mm	222mm	145mm

10KG/23.5L refilled LPG cylinder

Brief introduction

Production standard: ISO4706; ISO22991; GB5842-2006

Material: cylinder body-SG295 (HP295)

Handle and base-Q235

Thickness of wall:2.5mm

(we can use more thickness steel if you have request)

Work pressure: 2.1MpaTest pressure: 3.2Mpa

Cylinder color can be changed as your request.

Gas valve can be changed other styles to suit for different area.

Specifications:

MODEL:LPG-10KG
Water Capacity	High total	Bottle		Handle		Base		Angle Valve
		Diameter	High	Diameter	High	Diameter	High	As your request
23.5L	526mm	314mm	376mm	190mm	150mm	240mm	48mm

12.5KG/26.5L refilled LPG cylinder

Brief introduction

Production standard: ISO4706; ISO22991; GB5842-2006

Material: cylinder body-SG295 (HP295)

Handle and base-Q235

Thickness of wall: 2.75mm

(we can use more thickness steel if you have request)

Water capacity: 35.5~35.7L

Net weight: 16.2kgs

Test pressure: 34 Bar

Work pressure: 18 Bar

Cylinder color can be changed as your request.

Gas valve can be changed other styles to suit for different area.

Specifications:

MODEL:LPG-12.5KG
Water Capacity	High total	Bottle		Handle		Base		Angle Valve
		Diameter	High	Diameter	High	Diameter	High	3/4-14NGT F20/F27mm
26.5L	590mm	294mm	470mm	222mm	145mm	303mm	68mm

15KG/35.7L refilled LPG cylinder

Brief introduction

Production standard: ISO4706; ISO22991; GB5842-2006

Material: cylinder body-SG295 (HP295)

Handle and base-Q235

Thickness of wall: 2.75mm

(we can use more thickness steel if you have request)

Water capacity: 35.5~35.7L

Net weight: 16.2kgs

Test pressure: 34 Bar

Work pressure: 18 Bar

Cylinder color can be changed as your request.

Gas valve can be changed other styles to suit for different area.

Specifications:

MODEL:LPG-15KG
Water Capacity	High total	Bottle		Handle		Base		Angle Valve
		Diameter	High	Diameter	High	Diameter	High	3/4-14NGT F20/F27mm
35.7L	670mm	314mm	520mm	228mm	145mm	303mm	68mm

20KG/47L refilled LPG cylinder

Brief introduction

Production standard: ISO4706; ISO22991; GB5842-2006

Material: cylinder body-SG295 (HP295)

Handle and base-Q235

Thickness of wall:3.0mm

(we can use more thickness steel if you have request)

Test pressure: 3.2Mpa

Work pressure: 2.1Mpa

Cylinder color can be changed as your request.

Gas valve can be changed other styles to suit for different area.

Specifications:

MODEL:LPG-20KG
Water Capacity	High total	Bottle	Handle		Base		Angle Valve
		Diameter	Diameter	High	Diameter	High	As your request
47L	823mm	320mm	190mm	150mm	240mm	48mm
