Intruction for 13mm Cable Laying Tools Fiberglass Conduit Duct Rodder
Fiberglass cable duct rodder is selected as special tool for pulling electric cables and optical fiber cables in telecom, power industries, buildings and many other fields. rod is made of fiberglass and high strength
resin at high temperature, it is coated by high density polyethylene engineering plastic as its protectedlayer, which makes the duct rodder cover sliding on surface, durable,corrosion resistant and has good insulation
performance, these make it safe for using in cable occupied duct. Along with pull head and handcart,
it features easyto move and operate. fiberglass duct rodder will be equipped with different size of reels in
accordance with the length of the rod, there are wheels on the reel to make it convenient for moving,
it is an ideal tool for laying cables.
Features of 13mm Cable Laying Tools Fiberglass Conduit Duct Rodder
1.Constructed of fiberglass reinforced in the center and consists of a rugged plastic layer that could ensure the lifetime of the flexible rod.
2.The copper wire inside make tracing more easily.
3.Surface with ABS coated as its protected layer. The ABS is one kind of high quality polyethylene,which has good anti-UV capability, the advantage of smooth, longer service life and wear-resistant.
4.Rolling bearing cage flotation for mobility should be light and easy to use.
5.The meter mark on the rod is good for the actual usable length.It is more effective for the work.
6.The copper head is more strength and easily use.
7.The metal frame with rubber wheels,brake.Wheel assembly for easy transportation,the brake for flexible adjust the usable length.
Specification and material for 13mm Cable Laying Tools Fiberglass Conduit Duct Rodder
|
Specification |
Rod diameter |
13mm |
|
Rod length
|
150 meters
|
|
|
Most popular size (OD*L)
|
4.5mm*80m,6mm*80mm,6mm*120m,8mm*150m,10mm*200m, 12mm*250m,14mm*300m,16mm*300m,etc. |
|
Frame size |
48*45*20cm,65*50*20cm,98*90*40cm,100*100*45cm, 122*118*45cm,150*155*45cm |
|
|
Material
|
Inner wire |
Copper wire inside. |
| Rod inner | Extruded by fiber glass and high strength resin at high temperature | |
| Rod outer | Medium density ABS resin. | |
| Rod color | Blue,yellow,red,orange,white,etc | |
| Drawing head | copper | |
| Frame | Iron with spray coating |
|
| Wheel | Rubber | |
| Brake | Yes | |
|
Physical Property |
Line density |
55g/m |
| Working temperature | -40℃ to +80℃ | |
| Pulling break tension | Max.4500KGS | |
| Bending Radius | 295mm | |
| Technology | Pultrusion |
Detailed picture for 13mm Cable Laying Tools Fiberglass Conduit Duct Rodder
Packaging
Package inside Packaged with plastic woven strip
Package outside Carton. Or as request.
Shipping
1.FEDEXDHL/UPS/TNT express post for several sets.
2.By LCL/FCL sea shipment for batch goods.
3.Delivery time:9-25days after receiving your payment.
1. Your inquiry related to our products or prices will be replied within 24hours
2. The best prices based on same quality.
3. Guarantee samples quality same as mass production quality.
4. Professional Packing,Avoid damage
5. We can do OEM
1.What's the MOQ of trial order?
Without limit,we could offer the best suggestions and solutions according to your requirement.
2.Can we visit your factory?
Of course,welcome at any time.
3.After an order is placed,when the goods will be desptched?
10-25 days.
4.Is your company accept customization?
We accept OEM services.
5.How to solve quality problems?
If the products are not conform to customer samples or have quality problems, our company will be
responsible to make compensation for it.
Tianjin Talents International Trade Co., Ltd. was registered in Tianjin China in 1995, from then on, we devoted ourselves to the handlings of the supply to the oversea markets of fiberglass products,especially in fiberglass duct rod, fiberglass poles and special shaped products.Tianjin Talents is the Gold Supplier in Alibaba,we can provide Trade Assurance to ensure the safe of your money.We will provide the customized service and the professional after-sales service.
Enquiry Note:Please tell me the diameter and that i give you exact price and products.
