High mast lighting tower telescoping telecommunication antenna tower mast pole

Name: High mast lighting tower telescoping telecommunication antenna tower mast pole
Brand: mast lighting tower
Price: USD $500 - 800 / Unit

FOB Price

USD $500 - $800 / Unit

1 Unit(Min.Order)

Supply Ability 300 Unit / Units per Month
Port Shenzhen China
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:

mast lighting tower

Place of Origin:

Tianjin, China

Model Number:

TAL-H-006

Product Description

High mast lighting tower and telecommunication antenna tower mast pole

Specifications of High mast lighting tower
Closed length:	1.7m
Extended length:	6.0m
Max.payload:	30kg
Diameter range	50mm-90mm
Material:	Main Pole: aluminum alloy , stainless steel, fiberglass Bottom base,rotation platform and tripod: iron steel
Color of telescopic mast antenna mast	We usually process three colors of Army green, the original color of aluminum, black, but any particular colour OEM is available, most of the customers prefer army green. The whole unit will be in army green when closed, but when extended, the main pole will be in origin color of aluminum alloy only with top 4cm of each pole section in army green color.
Appllication	Telescopic mast antenna mast is suitable for car,ship or land.It can help light transmission and camera and other equipment rise and drop to a predetermined height after its work.The company's products are also widely used in golf, soccer stadium lighting at night.

Extended height (m)	Closed height (m)	Section number	Top diameter (mm)	Bottom diameter (mm)	Loading weight (kg)
4	1.47	3	30	50	1-15
5	1.20	5	30	80	1-15
6	1.50	5	30	70	1-15
6	1.30	6	50	160	1-60
6	1.70	5	60	130	1-50
8	1.65	7	30	90	1-15
9	1.80	7	30	90	1-15
9	1.80	7	40	105	1-30
10	2.10	6	30	80	1-10
10	1.95	7	30	90	1-15
10	1.95	7	40	105	1-30
10	1.95	7	50	130	1-60
12	2.10	8	30	105	1-15
12	2.10	8	40	130	1-30
15	2.40	8	30	105	1-15
15	2.40	8	40	130	1-30
18	2.45	9	30	130	1-10
18	3.00	8	50	150	1-30
20	2.90	9	30	130	1-10

Detailed Images

Accessories of High mast lighting tower
Main pole	1 unit
Pulling cord box with handle bars	3units
Handle lifting bar	2pieces
Tripod	1unit
Stainless steel sticks	6pieces
Ground anchor	3 pieces
Hand- operated valve (pneumatic mast)	1 piece
Air compressor(pneumatic mast)	1 piece
PU tube(pneumatic mast)	2 piece
Top platform	1 piece
Motor(electric mast)	1 piece
Electrical equipment control box(electric mast)	1 unit
Remote-controller(electric mast)	2 piece
Car clamps (when mouted on the car)	1 piece
Top plate( can be customized)	1 piece

Packing & Delivery

PACKING:

One unit of High mast lighting tower to be wrapped with Poly tapes and then put into carto.

Installation Instructions:

1)The High mast lighting tower can be installed on the ground, or on the vehicle. No matter where to install, its installation shall keep vertical with the ground.Tilted telescopic antenna mast will affect the rise and fall of itself, and if the lifting rod tilts seriously or maintain a long time, damage and danger could not be avoided.
2)The High mast lighting tower needs to be installed on a fixed object, without any shaking, such as walls, car body, or pile. At least two fixed points will be installed, and one point must be installed on the body of the telescopic antenna mast. And the distance between two points should be longer than 2/3 of the height of telescopic antenna mast. Its connection must be solid and reliable.

Warranty period

Except the damages due to misuse, unauthorized modification and man-made sabotage, the damaged parts will enjoyed free after-sales maintenance within one year's time from the date of delivery on the condition that the buyer himself will bear the shipping cost back and forth and the said damage should be confirmed by the seller through photos and description.

Workshop

Our Service

OEM/ODM service available for the buyers
Professional team for consulation, solution and designing
Complete quality control system before delivery
Multi-way fast delivery channel at buyer's option

One year free after-sale warranty after delivery

Our Company

Talents is a Chinese company that design, manufacture and supply a range of manual/electric/pneumatic/hydraulic operated telescopic masts and lifting devices that made of aluminum alloy tube, stainless steel tube, fiberglass tube and carbon fiber tube.
Our masts are CE certified, we are providing customers an one for one timely information feedback.We are continually developing new products to meet customer requirements, what you are asking for is our motive power of task, we wish one of our products will well-meet what you demand.
