Nylon Micron Flour Mill Mesh

Product Description

Flour mill mesh is a kind of monofilament thread/double thread woven fabrics, suitable for flour milling and some related

separation fields..
Majorapplication of MAISHl flour mill sieves:
1. Dry separation-Separation of different materials on the basis of their particle shape-Foods, chemicals, pharmaceuticals,

minerals, animal feeds, grains;
2. Dry classification-Separation of solid particles into precise sized fractions-Foods, chemicals, minerals and metals, pulp

and wood products, pharmaceuticals, fertilizers, abrasives
3. Solid/Liquid separation_Dewatering of solids and clarification of liquids_Foods, chemicals, pulp
4. Solids classification inliquid medium-Separation of solids into sized fraction in aliquid medium-Chemicals, minerals, pulp

and paper, ceramics, waste disposal.

MAISHl nylon flour mill mesh includes three series: PA-GG, PA-XX and
PA-XXX. Both monofilament and multifilament are available. Due to the good performance of PA6 and PA66, nylon flour mill

mesh is widely used in milling
industry, such as flour milling, corn milling and other grains milling

MAISHl nylon flour mill mesh includes three series: PA-GG, PA-XX and
PA-XXX. Both monofilament and multifilament are available. Due to the good performance of PA6 and PA66, nylon flour

 mill mesh is widely used in milling
industry, such as flour milling, corn milling and other grains milling

PA-XX Series Specification:

1. Mesh count: PA3XX-PA25XX

2. Width: 110CM, 127CM,158CM

3. Color: White

4. Roll length: 30m, 50m, 30yards, 50yards, 60yards

PA-XXX Series Specification:

1. Mesh count: PA3XXX-PA17XXX

2. Width: 110CM, 127CM, 158CM

3. Color: White

4. Roll length: 30m, 50m, 30yards, 50yards, 60yards

Characters

1.Nylon has excellent resistance to most common solvents and will operate continuously at temperatures up to 100°C in the

chemical pH range 7-14.

2.Good abrasion resistance and low coefficient of friction.

3.Working temperature is typically around 120°C.

4.Water absorption is very high.

5.Softening point is between 170°C and 230°C

lting point is between 210°C and 250°C

7.Excellent Tear Resistance

8.Excellent Dimensional Stability

9.Higher Tension Strength & Break Point

Application

Flour mill mesh is a kind of monofilament thread/double thread woven fabrics, suitable for flour milling and some related separation fields..

Major application of MAISHI flour mill sieves:

1. Dry separation -Separation of different materials on the basis of their particle shape -Foods, chemicals, pharmaceuticals, minerals, animal

feeds, grains;

2. Dry classification -Separation of solid particles into precise sized fractions -Foods, chemicals, minerals and metals, pulp and wood products,

pharmaceuticals, fertilizers, abrasives

3. Solid/Liquid separation -Dewatering of solids and clarification of liquids -Foods, chemicals, pulp

4. Solids classification in liquid medium -Separation of solids into sized fraction in a liquid medium -Chemicals, minerals, pulp and paper,

ceramics, waste disposal.

Production Process

We buy yarn from Jintong, Switzerland and Japan, we inspect the yarn when they unloaded in our factory. (tolerance, tensile strength,

physics test etc.).

After that, we put the warp wire on beam, draw the warp wire into heddle and reed. Then our experienced weaver will start weaving

according to orders.

Initial survey will be done after weaving.Then start heat setting treatment and physical properties inspection, before we get tentative

finished rolls(60-500 meters big rolls).

In the end, we'll cut the small rolls(20m-50m) according to customer orders after a final inspection.

Packing

We have two kind of packing type:

1.Fold the mesh into plastic bag ,then in carton.Suitable for small quantity and have no requirement on the crease.

2.Pack the mesh with paper and plastic bag,then in carton.Suitable for large quantity and the mesh has better surface then folding type.

Payment

1) 100%T/T in advance if order amount less than USD10000.00

2) 30% paid in advance and 70% balance paid before shipment if order amount more than USD10000.00.

3) 100% Irrevocable L/C payment is workable.

Any other payment term can be negotiatory.
