Sintered Powder Tube

Sintered Powder Tube Feature

1. Sintered Powder Tube is made from stainless steel powder particle or titanium powder particle

2. Sintered Powder Tube is sintered in a high temperature vacuum furnace. So stainless steel powder particle or titanium powder particle will not shed

3. Sintered Powder Tube is surface filtration and depth filtration

4. Sintered Powder Tube has narrow pore size distribution

5. High dirt holding capacity

6. Good porosity

7. High filter rating accuracy

8. The effect of filtration is good

9. High filter efficiency

10. Good permeability

11. Pressure loss is low in filtration process

12. High flow rate at low differential pressure

13. High compression strength

14. Good mechanical strength

15. Good abrasion resistance

16. Good durability against most liquids, gases and aggressive steam

17. High temperature resistance

18. High corrosion resistance

19. Backwash

20. Washable and Cleanable

21. Reusable

22. Long service life

23. Easy to be welded

Sintered Powder Tube Technical Data

Raw Material: SS 316L,Titanium

Filter Rating: 0.22-100 Microns

Operation Temperature: ≤ 816 ℃

Outside Diameter: 12 mm, 25 mm, 30 mm, 50 mm, 60 mm, 65 mm, 80 mm, 90 mm, 100 mm

Length: 254 mm, 508 mm, 762 mm, 1016 mm or others

Application

1. Steam filtration

2. High temperature liquid filtration

3. High temperature gases filtration

4. Catalysts powders recovery

5. Precoat support filtration
