Industry Refrigerating Chiller

Industry Refrigerating Chiller thumbnail-1
Industry Refrigerating Chiller thumbnail-2
Industry Refrigerating Chiller thumbnail-3
Industry Refrigerating Chiller thumbnail-4
Industry Refrigerating Chiller photo-1
Industry Refrigerating Chiller photo-2
Industry Refrigerating Chiller photo-3
Industry Refrigerating Chiller photo-4
US$ 3,000 - 6,880 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
XIECHENG
Place of Origin:
Guangdong, China
Certification:
CE
Contact Supplier Request Quote Chat Now
Meihua Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Jiangmen/Guangzhou/Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name XIECHENG
Place of Origin Guangdong, China
Certification CE
Warranty 1 year
Weight 650KG
Dimension(L*W*H) 1860*1100*1600MM
Condition New
Voltage 380V/50HZ/3PHASE as usual

industry refrigerating chiller

industry refrigerating chiller
industry refrigerating chiller industry refrigerating chiller industry refrigerating chiller

XIECHENG 15HP/45KW/12Ton Industrial Water Chiller for All Kinds of Factories and Plants



The Water Chiller is to provide a cooling process for better industrial production. In plastic molding industry,

it improves quality of molded products and shorten period of injection molding cycles.

Hence maximizes productivity of plastic molding manufacturing.

And water could be used in various of different industries, just depends on the needs.



What we PROVIDE with XIECHENG Industrial Water Chillers ?



1. A-class compressors from famous brands, high efficient shell condensers and evaporators*

    -- excellent cooling, quiet with low electric consumption.

2. Microprocessor control--easy to operate;

3. Special open type reservoir tank with stainless steel--easy to clean and maintain;

4. Well designed and reasonable Pipelines—ensures power supply and saves energy;

5. Precise electronic thermostatic controller--accurately maintains temperature range from 30C to 50 0C *;

6. Current-overload protector, high-and-low pressure switches, electronic time delayer, fault display system--Safe and durable;

7. Liquid crystal display showing temperatures of outlet and inlet chill water--provides visualized and direct setting;

9. Single, double or quadruple compressors combination available--economic and efficient;

10. Industrially designed--elegant and economic with friendly connections between human & machine.

“*”: Refers to depending on customer’s requirement; Ultra low temperature down to -30  0C available with Ultra Cooling Models.

industry refrigerating chiller

industry refrigerating chillerindustry refrigerating chillerindustry refrigerating chiller

Product specification:

Model UNIT XC-LF15A
Refrigerating Capacity kw 45
Kcal/h 38700
Compressor Input Power(kw) 4.5*2     /  *   9
Rated Power(Hp) 5*3    / * 7.5*2/ * 15*1
Evaporator Type *Water Tank with Pipe Coil
Pipe Diameter(inch) 2"
Refrigerant Type * R410a/R407c/R134a/R22
Filling Quantity(kg) 5
Cooling Flow(m³/h) 4.42
Air Cooled Condenser Type Finned condenser
Fan Power(kw) 0.75*2
Water Tank Capacity(L) 200
Pump Power(kw) 1.5
Flow(L/min) 200
Dimension(L*W*H, mm) 1850*1000*1640
Operating Weight(kg) 750
Voltage *380V/50Hz/3phase
* Customizable according to client's requirement

industry refrigerating chiller

industry refrigerating chillerindustry refrigerating chillerindustry refrigerating chillerindustry refrigerating chiller



Model UNIT XC-LF1A XC-LF2A XC-LF6A XC-LF10A
control method P.I.D
Refrigerating Capacity kw 2.77 5.28 15.22 30.5
Kcal/h 2382 4541 13091 26230
Compressor Input Power(kw) 0.89 1.77 5.2 4.5*2
Rated Power(Hp) 1 2 6 5*2
Evaporator Type *Water Tank with Pipe Coil/ Shell and Tube
Pipe Diameter(inch) 6' 6' 1" 2"
Refrigerant Type R407c/R410a/R134a/R404a/R22
Filling Quantity(kg) 1.6 1.8 2.5 5
Cooling Flow(m3/h) 0.476 0.908 2.6 4.42
Air Cooled Condenser Type Fined copper tube+low noise rotor fan
Fan Power 85*1 85*1 135*2 420*2
Water Tank Capacity(L) 20 20 60 110
Pump Power(kw) 0.37 0.37 0.75 0.75
Distance(m) 23 23 35 13
Flow(L/min) 100 100 110 200
Safety Protector high and low pressure protection, overload protection, over temperature protection ,phase sequence protection,etc.
Package Dimension(L*W*H,mm) 800*490*898 795*566*1058 1280*630*1118 1550*830*1543
"*" means optional or customizable. Capacity based on voltage 380V/50Hz/3Ph.
Not all models are showed in above parameters.
